NES Top Loader Recap + PPU Copper Mod (Reducing Jailbar Interference)
Автор: ReviveMyRetro
Загружено: 2026-03-13
Просмотров: 125
Описание:
In this video I restore a NES Top Loader (NES-101) by replacing the aging capacitors and performing a PPU shielding modification to help reduce the well-known jailbar interference in the video output.
Over time the capacitors in these systems degrade, which can affect power stability and video quality. After installing a full capacitor replacement kit, I also add grounded copper shielding around the PPU to help minimize interference that causes faint vertical jailbars on screen.
This is a great upgrade for anyone trying to get the cleanest possible video output from their NES Top Loader, especially when paired with RGB mods or modern displays.
🔧 Work performed in this restoration
Full capacitor replacement (recap)
Cleaning and inspection of the motherboard
Copper shielding installed around the PPU
Shield grounded to reduce video interference
System testing and video output check
If you enjoy retro console repair, restoration, and hardware mods, consider subscribing to ReviveMyRetro for more projects like this.
#NES #Nintendo #RetroGaming #ConsoleRepair #ReviveMyRetro
