Build Intuitive C-More EA9 HMI Menus That Operators Actually Use

Описание: Master C-More EA9 HMI navigation! Stop struggling with complex interfaces - learn to create intuitive common screen menus that operators love.

📖 FULL WRITTEN TUTORIAL + DOWNLOADS
https://accautomation.ca/c-more-ea9-h...

⏱️ TIMESTAMPS
0:00 - Introduction - C-More EA9 HMI Common Screen Menus
0:40 - Review Previous Program Screens
1:52 - Creating New Common Screen Menu Page
2:25 - Adding Change Screen Push Buttons
3:42 - Configuring Previous/Forward Navigation
4:56 - Adding Screen Selector Object
6:46 - Setting Background Screen Properties
8:21 - Program Simulation and Testing
9:34 - Downloading to HMI Panel
10:29 - Live Testing on C-More EA9 Panel

📚 WHAT YOU'LL LEARN
✅ How to create common screen menus for easy HMI navigation
✅ Setting up background screens and change screen push buttons
✅ Configuring screen selector objects with popup functionality
✅ Best practices for intuitive operator interface design
✅ Testing and downloading programs to C-More EA9 panels

🔗 MORE RESOURCES
▶ Series: https://accautomation.ca/series/c-mor...
▶ PLC Beginners Guide: https://accautomation.ca/programming/...
▶ Free eBooks: https://accautomation.ca (subscribe for download)

🛒 RECOMMENDED HARDWARE
▶ Training Kits: https://accautomation.ca/series/c-mor...

💬 Questions? Drop a comment below.

🔔 New tutorials every Monday — Subscribe and hit the bell!

#PLC #HMI #IndustrialAutomation #LadderLogic #AutomationDirect #PLCProgramming #ACCAutomation


There are several reasons that we are using the EA9-T10CL C-More HMI Panel. Here are a few:
• Touch screen display (LCD) 280 NITS display brightness
• 10.4” diagonal colour TFT (Thin Film Transistor)
• Analog resistive (1024 X 1024) touch screen allowing unlimited touch areas
• EA9-PGMSW programming software
• 800 x 600-pixel display
• 64K colours
• 50,000-hour average backlight half-life
• USB port B (program/download) and USB port A (USB device options)
• Ethernet 10/100 Base-T port (program/download & PLC communication
• Remote Internet Access
• Serial PLC interface (RS-232/422/485)
• One built-in SD memory card slot
• 12–24 VDC powered (18W), 110VAC power adapter (optional)
• Audio Line Out, stereo - requires amplifier and speaker(s)
• 26MB project memory
• Data logging
• 0 to 50°C [32 to 122°F] operating temperature range
• NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only
• Slim design saves panel space
• UL, cUL & CE agency approvals
• 2-year warranty from date of purchase
