Mastering C-More EA9 HMI Alarm Objects: Your Complete Guide

Описание: We will now look at the C-More Alarms in the EA9 HMI. The C-More HMI Panel software uses virtual components called Objects. These objects are programmable to simulate the functions that you require on your automation project. Pushbuttons, Switches, meters, and graphs are just a few of the objects that are available to you.
The Alarm List Objects include a variety of options to customize the display of
alarms as a screen. This is in addition to the alarm banner at the bottom of the screen that shows the active alarms. We also have the Alarm Screen Style setting in Panel Manager.
We will now look at the object list alarms that we can use with our HMI panel. The alarm objects that are available on the C-More EA9 are the Alarm List and Call Alarm Screen. Alarms are specified as an event in the C-More HMI panel. We will program both discrete (On/Off) and limits on a range for our event alarms. Let’s get started.

More information can be obtained on our website. This includes all of the links mentioned in this video.
https://accautomation.ca/c-more-ea9-h...

00:00 C-More EA9 HMI Series Panel Object List Alarms
00:36 Setting Our Alarm Screens – C-More
05:44 Event Manager Database (Alarm Database)
11:33 C-More Alarms Simulation
14:00 Transfer HMI Program to C-More
15:16 C-More Alarms PLC Program Additions
