Building Your First HMI Control Panel from Scratch

Описание: We will now put our first program into the C-More EA9 HMI Panel using the C-More programming software. The Do-more Designer Simulator will be used with a modified Start Stop Jog Circuit so we can use our HMI screen to monitor the output as well as control the inputs on the PLC.
Communications will be established to our C-More EA9-T10CL unit and the firmware will be updated. We will then develop our control for our PLC ladder logic circuit.
The PLC logic for our circuit can be found in our post: How to Make a Start / Stop / Jog Circuit in a PLC. Our C-More EA9 HMI Panel will be communicating to the PLC simulator via Ethernet with the Modbus TCP protocol. Let’s get started.
c-more first program

More information can be obtained on our website. This includes all of the links mentioned in this video.
https://accautomation.ca/c-more-ea9-h...

00:00 C-More First Program - EA9 Series
00:33 Page Display - Zooming
01:32 Panel and Communication Setup
02:20 Review of PLC Program and Addresses
03:16 Adding C-More Pushbuttons - Start Stop Jog
07:07 Adding C-More Indicator Light
08:42 Transfer and Test Program

Establishing Communication and Updating Firmware Video
   • Master C-More HMI Programming: Live PLC Co...
First Program Video
   • Building Your First HMI Control Panel from...

Previously we have discussed the following in our C-More HMI Panel:
System Hardware
https://accautomation.ca/c-more-micro...
Unboxing and Review Video
   • C-More Micro HMI Hardware Unboxing and Review
Powering the Unit
   • C-More Micro HMI Installing the Software
Installing the Software
https://accautomation.ca/c-more-ea9-h...
   • C-More EA9 HMI Programming Software Instal...
System Setup Screens
https://accautomation.ca/c-more-ea9-h...
   • C-More EA9 HMI Series Panel System Setup S...

There are several reasons that we are using the EA9-T10CL C-More HMI Panel. Here are a few:
• Touch screen display (LCD) 280 NITS display brightness
• 10.4” diagonal colour TFT (Thin Film Transistor)
• Analog resistive (1024 X 1024) touch screen allowing unlimited touch areas
• EA9-PGMSW programming software
• 800 x 600-pixel display
• 64K colours
• 50,000-hour average backlight half-life
• USB port B (program/download) and USB port A (USB device options)
• Ethernet 10/100 Base-T port (program/download & PLC communication
• Remote Internet Access
• Serial PLC interface (RS-232/422/485)
• One built-in SD memory card slot
• 12–24 VDC powered (18W), 110VAC power adapter (optional)
• Audio Line Out, stereo - requires amplifier and speaker(s)
• 26MB project memory
• Data logging
• 0 to 50°C [32 to 122°F] operating temperature range
• NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only
• Slim design saves panel space
• UL, cUL & CE agency approvals
• 2-year warranty from date of purchase
