Master Your First BRX PLC Program: Start-Stop-Jog Circuit

Описание: We will now look at writing our first program for the BRX Do-More PLC. The Do-More Series allows us to write programs for the PLC controller, whether online or offline. The series will also allow us to do online editing. We can change program information and download the new program between scans of our controller. As a system integrator, this ability can be very useful in the field when troubleshooting your automation system.
Our first program will be the start-stop-jog circuit. Here is a link to an explanation of the circuit's logic.
How to Make a Start-Stop Jog Circuit in a PLC
https://accautomation.ca/how-to-make-...
Let's get started.

More information can be obtained at our Website. This includes all of the links mentioned in this video.
https://accautomation.ca/brx-plc-firs...

00:00 BRX Do-More PLC First Program
00:18 Programming Ladder Logic – BRX Do-More
06:33 Documentation of the Ladder Logic
08:30 Connect to the PLC – BRX Do-More
10:10 Downloading the Program – BRX Do-More

Previously in this BRX Do-More Series PLC, we looked at the following:
System Hardware
https://accautomation.ca/brx-plc-syst...
System Hardware Video
   • BRX Do-More PLC System Hardware
Unboxing Video
   • BRX Do-More Series PLC Unboxing
Installing the Software
https://accautomation.ca/brx-plc-inst...
Installing the Software Video
   • BRX Do-More PLC Installing the Software
Establishing Communication
https://accautomation.ca/brx-plc-esta...
Establishing Communication Video
   • BRX Do-More PLC Communication Setup - USB,...
Updating Firmware Video
   • BRX Do-More PLC: Connect & Update via USB,...
Numbering Systems and Addressing
https://accautomation.ca/brx-plc-numb...
Numbering Systems and Addressing Video
   • BRX Controller Memory Allocation | Do-More...

There are several reasons why we are using the BRX Series Controller. Here are just a few.
Standalone PLC with built-in I/O
Built-in Data Logging
Communication ability - Ethernet Port, RS232, RS485, USB - support for protocols such as Modbus RTU, Modbus TCP, ASCII, K-sequence (DirectLOGIC users), Custom Protocols (ASCII over serial, TCP or UDP over Ethernet)
Built-in Analog input and output
Integrated motion control
High-speed counters
Powerful instruction set (Video of Instructions in software)
Ability to expand the system with a variety of modules
Part of the Do-More series of PLCs which use the same free software. (Do-More Designer)
Integrated simulator in the software capable of external communications for testing

The BRX series of programmable logic controllers consist of four different units. They differ depending on the Inputs and Outputs built into the unit and if it has an ethernet port.
No I/O Micro PLC unit – (BX ME)
10 Point Micro PLC unit – (BX 10/10E)
18 Point Micro PLC unit - (BX 18/18E)
36 Point Micro PLC unit - (BX 36/36E)
These CPUs (Central Processing Units) are also known as MPU (Multi-Processing Units) because of the communication capabilities.
