Tutorial Safety Designer (Part 2/2): Configuring Muting Parameters with deTec4 and DMM4

Описание: Master the configuration of muting parameters for the deTec4 and DMM4 with our comprehensive Safety Designer tutorial. This video is the second step in setting up a 4-signal muting solution, following the hardware configuration. Download the Safety Designer for free on sick.com.

In this video, you will learn:
How to connect the deTec4 and DMM4 to the Safety Designer
Viewing live status and error messages of connected devices
Configuring Application Diagnostics Output for external muting lamps
Activating and setting up muting, including Entry/Exit monitoring and T-Muting with 4 sensors
Adjusting muting parameters such as concurrence monitoring time, direction detection, and total muting time
Setting up partial muting and configuring object height using live beams
Creating and managing up to 3 different muting modes with specific parameters.

Please note that you can use the DMM4 extension module not only for the deTec4 safety light curtain, but also for the deTem4 A/P and deTem4 safety light-beam sensors. Visit our website for additional information and to download the Safety Designer software.

Click here for more information:
https://www.sick.com/DMM4

Video chapters:
0:00: Introduction
0:37: Live-status and diagnosis in the configuration window
1:14: Muting options
2:06: Setting the muting application parameters
2:34 Partial muting and object heights
3:12: Three operating modes
4:16: Transferring and verifying the configuration
4:31: Wrap-up
