Intersection of two interpenetrating Solids
A vertical cylinder of diameter 70 mm is completely penetrated by another horizontal cylinder of diameter 50 mm, their axes bisecting each other at right angles. Draw their projections showing curves of intersection, assuming the axis of the penetrating cylinder is parallel to parallel to both H.P. and V.P. Height/length of the cylinders may be assumed suitable.
#drawing
