Gate 2006 pyq CAO | The data path shown in the figure computes the number of 1s in the 32-bit
Автор: Gate CS pyqs - the other way [Eng]
Загружено: 2022-04-30
Просмотров: 800
Описание:
The data path shown in the figure computes the number of 1s in the 32-bit input word corresponding to an unsigned even integer stored in the shift register.
The unsigned counter, initially zero, is incremented if the most significant bit of the shift register is incremented if the most significant bit of the shift register is 1
IMAGE NOT SUPPORTED
The micro-program for the control is shown in the table below with missing control words for micro-instructions I1, I2, ….. In.
Microinstruction Reset_Counter Shift_left Load_output
BEGIN 1 0 0
I1 ? ? ?
: : : :
In ? ? ?
END 0 0 1
The counter width (k), the number of missing micro-instructions (n), and the control word for microinstructions I2, ….. In are, respectively,
(A) 32, 5, 010
(B) 5, 32, 010
(C) 5, 31, 011
(D) 5, 31, 010
