Dirt cheap managed APC enterprise PDUs - can we take control?

Описание: I bought a pair of incredibly cheap high end 15 year old APC Power Distribution Units from facebook marketplace with a few friends. the reset procedure doesnt really work, and neither does DHCP. Let's try breaking in to this thing with a cheap RS232 cable and telnet!

AP7941 24 outlet 30A PDU NEMA 6-30R NEMA C14 Nema C20

commands:
sudo su (enter)
dmesg | less (enter)
q (enter)
apt-get install screen (enter)
screen /dev/ttyUSB0 (enter) - your ttyUSB value may be different than mine
(reset PDU)
(spam enter until you get user name to show up)
apc (enter)
apc (enter)
3 (enter)
1 (enter)
apc (enter)
apc (enter)
apc (enter)
(enter)
(enter)
4 (enter)
escape
escape
escape
4 (enter)
(kill screen instance on Linux, let PDU reboot)
(spam enter in new screen instance until it shows username)
3 (enter)
4 (enter)
2 (enter)
YES (enter)
4 (enter)
escape
escape
4 (enter)
(kill screen instance on Linux, let PDU reboot)
sudo su (enter)
arp -s (ip address you want the PDU to use) (PDU mac accress) (enter)
ping (ip address you gave the PDU in the last step) -s 113 (enter)
(remove ethernet from PDU, reset pin proceedure again, let it fully boot and restore config, solid green light on ethernet port with no cable..)
(plug in ethernet cable).
type in the ip address for the PDU in a web browser, and log in!


--------------

RS232 APC compatible cable used in this video: https://amzn.to/3pcxnp1
B250 motherboard: https://amzn.to/3VfJY6B
PDU I like: https://amzn.to/3ZfI1HP
5-15 C13 PDU adapters: https://amzn.to/3EBnR39
Smart plugs: https://amzn.to/3EzF0tY
VUE whole panel monitor: https://amzn.to/3XRbJlj
my favorite mining motherboard: https://amzn.to/3kv8Gl8
meter box for making sure your rig is behaving: themeterbox.com code DQBLIZZY for 10% off.

-----------------

00:00 Intro
01:31 factory reset
02:22 RS232 console connection
02:52 OS commands
03:56 TTY device ID
05:44 logging in to the PDU
06:01 PDU physical reset procedure
06:57 reset commands
09:32 setting the IP for management
11:53 web GUI login for APC PDU
13:14 feature overview of WebGUI
16:10 outro

-----------------
