NOTE 1. Yes, we plan to allow George to engage with the FCR, but only after we complete FCR development. Also, once the FCR is complete, we will add new datalink functions between aircraft. For now, AH-64D to AH-64D datalink is multiplayer-only.

NOTE 2. We will later add LINK mode that will slave the TADS to the FCR NTS.

NOTE 3. We will add the FCR to the reloading/refueling pop-up. This is currently planned for the January 2024 Open Beta update but is subject to change based on testing.

NOTE 4. As always, these videos provide a preview of an upcoming feature to assist you in understanding a new feature. Later, it is quite possible that the feature will change, and the feature functionality has changed. As much as I’d like to, I lack the time re-record these videos.

In this DCS: AH-64D video, we’ll discuss sending and receiving attack results over the datalink for better coordination between flight members. Once the battle is over, the flight lead can collect BDA Reports, or Battle Damage Assessments. As you probably noticed, each time you fire a missile, a green X appears on the FCR page, and on the TSD page if you have it set to Attack phase. These represent target locations that have been engaged with missiles, which you then review on the TSD SHOT page. It’s important to understand that these reports only indicate that a missile has been fired at a target, it does not indicate if the target was actually destroyed. In the second half of this video, we’ll discuss how to set FCR contacts as Target Points and ways to slave the TSD to an FCR-identified target.

To view my own SHOT file, I’ll press COORD at T5, then press SHOT at T6. Each target location that I shot a missile at will display its corresponding target symbol, the missile type as RF for a radar-guided missile, SAL for a laser-guided missile, the time that I launched the missile, and the coordinates of the target.

Note that these locations are recorded for all missiles, regardless of whether they were radar-guided or laser-guided variants, and regardless of whether I engaged with the FCR or the TADS. However, an Unknown square symbol will always be displayed for any engagements that are performed using the TADS, since only the FCR is able to classify a target type.

If I want to send my SHOT file to another flight member, I can do so on the TSD Report page. I select the main TSD page, select RPT at T1, and select BDA at L1. I have several options to choose from. I can send my own SHOT file to my Primary members by selecting OWN, or I can send ALL SHOT files on board my aircraft. When ALL is selected, the BDA report will include my own SHOT file as well as any other SHOT files that I’ve received from other flight members, allowing me to forward them to other flights as necessary.

Alternatively, I can request a BDA report from my teammate in the other aircraft, which I’ll do by toggling the MSG type from SEND to RQST (Request), select his callsign, and then press SEND. His system will automatically send me the data in reply to my request. Now, you can see additional green X symbols that are displayed in a dim green, which represent the locations that he has engaged.

If I return to the SHOT page, I can now see entries that are labeled as “DL”, for datalink SHOT files, in addition to my own SHOT file entries labeled as “OWN”. If I wanted to delete any SHOT file entries received over the datalink, I can press the DEL button on the left side. But I can’t delete any of my own.

I also want to go over how to store FCR targets as TSD Target points. This can be particularly useful if you intend to gather reconnaissance data on enemy positions which you intend to send to other AH-64D’s or to bring back with you for follow-on missions. Since the FCR data is overwritten after each scan, storing FCR targets in this manner can be a small but crucial capability that can pay dividends for large-scale missions.

You could also slave the TADS to the Target point to visually see if the target was destroyed. The FCR has no idea of a detected unit is destroyed or not.

The quickest way to store TSD targets from the FCR data is by pressing the TGT, or Target, button at L4 on the FCR page. When this is opened, the first Target point index that is unoccupied will be displayed on the right. I could cursor-select each FCR target I wish to store, but I’m in a hurry so I’m just going to select ALL and the entire 16 target shoot list is now stored, which is reflected in the list on the right.

Note that this function will only work if there are unoccupied Target points between T01 and T49. If T01-T49 are already occupied by target or threat points, FCR targets cannot be stored using TGT on the FCR page.
