Debugging EMC Conducted Emissions with a Spectrum Analyser. LISN setup for AC and DC-powered PCBs
Автор: Dr. EMC
Загружено: 2024-08-16
Просмотров: 1564
Описание:
In this video I demonstrate how to perform the measurement of conducted emissions with a Keysight n9000B spectrum analyser and a LISN. With one setup used for AC systems and another one for DC with two line impedance stabilisation networks featured in this video:
1. DC LISN:
https://www.tekbox.com/product/tboh01...
2. AC LISN
https://transientspecialists.com/prod...
TIMELINE:
00:00 START
00:38 Line Impedance Stabilization Network (LISN)
02:37 LISN setup for AC-powered PCBs with a Spectrum Analyser
11:21 Attenuation pad
12:39 Measurement result with an AC LISN
14:26 LISN setup for DC-powered PCBs with a Spectrum Analyser
24:00 Measurement result with a DC LISN
