How to Find Maximum Bending Stress in a overhanging T-Beam | Strength of Materials | TU, PU, PoU
Автор: Mr. Structure: Building Minds with Neeraj Bhandari
Загружено: 2026-03-10
Просмотров: 203
Описание:
In this video, we provide a step-by-step solution to a problem involving overhanging beam with T -cross section from the chapter "Flexural Equation" which was also asked in Question 5(a) in the 2025 Pokhara University Final Examination.
This problem focuses on finding the Maximum Bending Stress in a T-beam subjected to a Uniformly Distributed Load (UDL) and a point load on a cantilever overhang.
Key Steps Covered :
Reactions: Calculating support reactions for the 6m span and 2m overhang.
Max Moment: Finding the maximum bending moment using the Shear Force and Bending Moment approach.
Section Properties: Locating the Neutral Axis and calculating the Moment of Inertia for the T-section.
Flexure Formula: Applying flexural equation to find the maximum stress at the extreme fibers.
Subscribe for more Pokhara University (PU) Past Paper solutions!
#pokharauniversity #puexams #structuralanalysis #appliedmechanics #bendingstress #civilengineering
