DIY 3DOF MOTION NEW SERIES GET YOUR DIY MOTION SIMULATOR UP AND RUNNING EPISODE 1 - COMPONENT BOX

Описание: NEW SERIES - Yes finally we are going to get the compact motion simulator up and running. the first thing we need to do is build t component box to house the arduino, the 3 IBT motor controllers, the power rail and the wiring distribution.

00:00 start
05:00 modifying the component box
10:00 fitting arudino, IBT-2 and wire distribution panel into place

MUSIC
provided by You Tube content free music
-----
EMAIL ME at - [email protected]
____
Tie rod ends :
https://www.amazon.com/dp/B00ELO68CK?...

50:1 12volt motors just search Ebay for GEAR MOTOR 12 VOLT GREAT FOR SAWMILL/CRAB POT PULL/FEED/SIMULATOR 75-80RPM 50:1 (sold by PGSAW in Canada)

Hall Effect Potentiometers DIGI-Key and others PN 987-1392-ND
https://www.digikey.co.uk/en/products...

Arduino UNO R3 - amazon. I have also used the cheaper ELEGOO clone.
https://www.amazon.com/Arduino-A00006...

IBT-2 motor controllers up to 43amps (which is a lot!)
https://www.amazon.com/dp/B00WSN98DC?...

other motor controllers you could consider using are JRK12V12 or Sabertooth but I use IBT-2's

XSIMULATOR forum - Info specifically for arduino/IBT-2 for 1 to 3 Motors. You can use up to three motors per arduino. But you each motor needs it's own IBT-2 controller.
https://www.xsimulator.net/community/...

DMAX motion sim build posts on XSimulator
https://www.xsimulator.net/community/...
