How to Wire a 13 Amp Plug Top BS 1363 - Connecting a MK U.K. Plug Top Tutorial and Step by Step

Описание: Appreciate electrician training on how to fit, change or wire an MK BS 1363 13 amp plug top. Includes a full demonstration on how to strip the 3 core flexible cable and connect it into a 3 pin 13 amp plug top. This video also help with the skills required to change, re-wire or replace a UK 13 amp 3 pin plug top. It is important when fitting plug tops to select the correct size BS 1362 fuse with the common sizes being 13, 5 and 3 amps.

Note If you have the cable length card then best practice is to follow the conductor length guide. I use this exercise to start working on hand eye coordination and don’t follow the saying if the plug top has a catastrophic event happen to it then we want the earth connection to be last to be pulled out and therefore somehow save the day. Do we apply the same rule for light switches and socket outlets always leaving the CPC longer than the live conductors in case it is pulled of the wall…

🔔 Subscribe for more free electrical training videos https://youtube.com/c/GSHElectrical?s...

== 🕐 Time Stamps - Cut to the action 🕕 ==

00:00 - How to connect a 13 amp plug top
00:51 - Screwed terminals and screwed cord grip
01:16 - Wrap around a post
02:11 - BS 1362 fuses
02:42 - Removing the screws
03:10 - EARTH
03:44 - Instructions on the plug
04:19 - Removing the outer PVC
04:56 - Electricians knife
05:43 - Burst through
06:25 - Exposing the conductors
06:56 - Line conductor
07:56 - Line conductor length
08:26 - Removing the brown PVC
09:17 - Connecting the line conductor
10:00 - Don't screw into the PVC
10:31 - Using the cord grip
11:14 - Earth conductor
12:24 - Connecting the earth
13:05 - Neutral conductor
13:44 - Connecting the neutral conductor
14:46 - Layout
15:23 - Don't put the fuse in

🔵 Flexible Cables Class 5 - Construction, Number of Conductors - BS 1363 Plug Tops and BS 1362 Fuses    • Class 5 Flexible Cables - Construction, Nu...

🔵 How to Fit, Wire or Change a 13 amp plug top - Wiring a UK BS 1363 Plug Step by Step Demonstration    • How to Fit, Wire or Change a 13 Amp Plug T...

🔴 eFIXX Different Classes of Conductor
   • UNDERSTANDING CLASSES of ELECTRICAL CONDUC...

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
