Class 5 Flexible Cables - Construction, Number of Conductors - BS 1363 Plug Tops and BS 1362 Fuses

Описание: In this video we take a look at class 5 flexible cables. In the early stages of training to be an electrician colleges work with flexible cables. These early practical exercises are making off a ceiling rose and pendant and a BS 1363 plug top. Understanding the construction of flexible cables in relationships to the conductor sizes, number of conductors and the fine copper strands making them a class 5 conductor. I also show the construction of a BS 1363 13 amp plug top and a BS 1362 fuses. All these skills are required for apprentice Electrician’s.

🔔 Subscribe for more free electrical training videos https://youtube.com/c/GSHElectrical?s...

🕐 Time Stamps - Cut to the action 🕕

00:00 - Class 5 flexible cables
00:29 - Construction of conductors
01:42 - Size of the earth in a flex
02:54 - Common number of conductors in flex
03:36 - Use of 2 core flex
04:22 - What's inside a BS 1363 plug top
04:58 - Why is earth connection is missing in this plug top
05:37 - Double insulated symbol
06:08 - Common sheath colours are white and black
06:32 - Using flexibles cables outside
06:47 - Gamming
07:00 - Extension leads
07:10 - Yellow flex 110 volts
07:15 - Blue flex 230 volts
07:35 - Construction of a plug top
08:05 - How do we open the shutters on sockets
08:36 - Why is the earth pin longer
09:31 - Issues with old 13 amp plug tops
10:37 - New plug top are safer
11:13 - 13 amp BS 1362 fuse
11:38 - Construction of a BS 1362 fuse
12:15 - If only we had one of these
12:49 - Using side cutters
13:23 - Using an electricians knife
14:21 - Practice
15:18 - Now that was easy
15:54 - Ferrules
17:09 - Improving the electrical connection
17:33 - On-Site Guide

🔵 How to Wire a 13 Amp Plug Top BS 1363 - Connecting a MK U.K. Plug Top Tutorial and Step by Step    • How to Wire a 13 Amp Plug Top BS 1363 - Co...

🔵 How to Fit, Wire or Change a 13 amp plug top - Wiring a UK BS 1363 Plug Step by Step Demonstration    • How to Fit, Wire or Change a 13 Amp Plug T...

🔴 eFIXX Different Classes of Conductor
   • UNDERSTANDING CLASSES of ELECTRICAL CONDUC...

🔴 eFIXX Improving the Electrical Connection with Ferrules
   • Ferrule crimping - An easy way to improve ...

Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E.
