Зарядное устройство автоматически отключается для всех типов аккумуляторов

Описание: @radal05
Charger otomatis cut off untuk semua jenis baterai cas aki FP5139
modul FP5139 XY-sjva-4
Adjustable Automatic Step-up and Down Voltage Regulator CVCC 0.5-30V

link pembelian :
1. https://tokopedia.link/t0hEWPEPRwb
2. Temukan Auto Buck Boost 35W 3A 5-30v to 0.5-30V CC CV Charger Step Up Down seharga Rp60.000. Dapatkan sekarang juga di Shopee!
https://s.shopee.co.id/4fagPZMjQc?sha...

Charger otomatis cut off untuk semua jenis baterai cas aki FP5139
Video yang berhubungan :
1. Adjustable Automatic Step up and Down Voltage Regulator FP5139 xy-sjva
   • Adjustable Automatic Step up and Down Volt...
2. Cara pasang volt ampere digital pada modul Power supply FP5139 xy-sjva
   • Cara pasang volt ampere digital pada modul...
3. skematik dan cara kerja FP5139 Automatic Step-up and Down xy-sjva
   • Automatic Step-up and Down  xy-sjva skemat...
4. Tambah kipas pendingin otomatis ON OFF power supply FP5139 xy-sjva
   • Tambah kipas pendingin otomatis ON OFF pow...
5. Lepas Ganti pasang potensiometer multiturn Auto Step Up Down FP5139
   • Lepas Ganti pasang potensiometer multiturn...

Charger otomatis cut off untuk semua jenis baterai cas aki FP5139
Description:
1. Can be boosted, but also buck, the output voltage 0.5-30V arbitrary adjustment, limiting current 0-4A arbitrary adjustment; can be used for LED constant current drive, battery charging and other constant current occasions, while limiting current with overcurrent protection, more secure ; Constant current mode indicator, charging indicator, full of light. Output anti-backwash, do not charge the battery when the additional anti-flooding diode.
2. XL6009 / LM2577 on the market using a single SS34 rectifier, the first pressure value is not enough, according to the principle of starting and lowering the rectifier and switch tube voltage value is greater than the maximum input voltage plus the maximum output voltage (if the input voltage and output voltage are the largest For the 30V, mos tube and Schottky's voltage at least to reach 60V), SS34 pressure up to 40V, 6009 maximum pressure 36V, this module design is the existence of security risks;
3. The current output capacity is not enough, the original SS34 maximum current 3A (coupled with switching losses, poor heat, the real current capacity can be less than 3A), Schottky once the voltage is too high or the temperature is too high will be broken, Whole module. There are security risks;
4. Finally, XL6009 / LM2577 program is low efficiency, ordinary inductive heat, not the buck chip, the lack of adequate protection.
5. The module uses the step-up and down the chip as the main controller, external 60V 75A MOS tube as a switch, double 60V 5A SS56 Schottky do rectifier.

Charger otomatis cut off untuk semua jenis baterai cas aki FP5139
Parameter:
1. Input voltage: 5-30V
2. Output voltage: 0.5-30V
3. Output current: to long-term stability in the 3A, to strengthen the heat can reach 4A
4. Output power: natural cooling 35W, strengthen the heat 60W
5. Conversion efficiency: 88% or so
6. Short circuit protection: Yes
7. Operating frequency: 180KHZ
8. Size: 65 * 32 * 21mm
9. Work temperature:-20~85Celsius

00:00 Radal05
00:12 Modul step up down
00:43 perhitungan Daya
04:00 Yang paling penting dalam mencharger
05:10 Menentukan arus charger
07:00 Menentukan tegangan cut off
08:00 Set besar arus charger
09:00 Praktek charger
Charger otomatis cut off untuk semua jenis baterai cas aki FP5139
