core barrel, wireline , thiree basic component, outer tube, inner tube head assembly, overshot, bit

Описание: ###core barrel assembly,#core barrel assembly animation,#ore Barrels kg lbs
1-13 306001 NQ Core Barrel 1.5 m / 5 ft 39.6 87.4
1-13 306002 NQ Core Barrel 3.0 m / 10 ft 61.1134.7
Standard Configuration Qty
1 3542751 NQ Head Assembly* 1
2 24909 Inner Tube, 1.5 m / 5 ft 1 2 24891 Inner Tube, 3.0 m / 10 ft 1
3 24893 Stop Ring 1
4 30488 Core Lifter 1
5 24892 C ore Lifter Case 1
6 3545405 NQ Full-Hole Tanged Locking Coupling 1
7 24896 A dapter Coupling 1
8 24897 Landing Ring 1
9 24910 Outer Tube, 1.5 m / 5 ft 1
9 24898 Outer Tube, 3.0 m / 10 ft 1
10 44407 Inner Tube Stabilizer 1
11 24900 T hread Protector 1
12 3541994 ITHT Product Manual (not shown) 1
13 306390 Safety Poster (not shown) Qty
1 42913 S pearhead Point 1
2 15141 Compression Spring 1
3 42914 Detent Plunger 1
4 3 540329 S pearhead Base 1
5 42905 Spirol Pin 7/16" x 1" 1
6 306455 Latch Retracting Case 1
7 24305 Spring Pin 1/2" x 2" 2
8 3541932 Nyloc Bolt 3/8”-16UNC x 3/4” 1
9 306022 Washer 1
10 3543812 Latch Compression Spring 1
11 3 541778 Upper Latch Body 1
12 104816 Latch 2
13 306454 Link 2
14 24548 Spring Pin 1/2" x 1-1/2" 1
15 62374 Stainless Steel Ball, 22 mm 1
16 62380 Landing Indicator Bushing 1
17 306009 Landing Shoulder 1
18 306008 Lower Latch Body 1
19 3548161 Washer, Nord-lock 1
20 2 4885 Hex Nut 1
21 24886 Spindle 1
22 44209 Shut-Off Valve, Hard 2
23 24888 Valve Adjusting Washer 2
24 24312 T hrust Bearing 1
25 24889 S pindle Bearing 1
26 18298 H anger Bearing 1
27 24313 Compression Spring 1
28 22918 S tover Lock Nut 1
29 40664 Inner Tube Cap Assembly (28A, B, C, D) —
29A 17447 G rease Fitting 1
29B 62374 Stainless Steel Ball, 22 mm 1
29C 40677 I nner Tube Cap 1
29D 37382 C heck Valve Body 1
