ATARI ST (1024STf) on GBS-8220
Автор: CHABBO
Загружено: 2013-02-17
Просмотров: 1099
Описание:
First test of the Atari 1024STf running on a modern monitor thanks to the GBS-8220!
Perfect replacement for the Atari SC1224,
Audio output optional, here I am just using a TVs AV input for audio out.
Program running is Music Mon 2, playing an example track.
For ATARI ST computers WITHOUT RF Modulators
ATARI 13-PIN DIN SIDE: GBS-8220 (5 PIN INPUT) (P3):
PIN 1 - AUDIO OUT
PIN 2 - C SYNC -------------------- S P3-pin 5
PIN 6 - GREEN --------------------- G P3-pin 2
PIN 7 - RED -------------------------- R P3-pin 1
PIN 10 - BLUE ------------------------ B P3-pin 3
PIN 13 - GROUND ------------------ G P3-pin 4
http://www.ebay.com.au/itm/GBS-8220-R...
http://www.retrocomputing.net/parts/a...
