S. 28th St. Double Railroad Crossing, MTS Trolley Light Rails Meet & Pass, San Diego CA

Описание: February 14, 2025 Valentine's Day
I finally got back out rail fanning after a long break for family plus the last few weeks I've been out I missed all trains. At Gaslamp I had seen the H-SDGBAR sitting near Fifth Ave but chose not to chase it as it was already rightvon top of me and would not be able to set up in time for the activation. Once I got to the National City yard, I saw the V-SDGCLO auto carrier train creeping towards Civic Center Dr but couldn't film it because the crossing activated as I tried to get setup, so Imcontinued north but turned around to see if the train would clear Civic Center Dr but it was too longnso I came here to catch it after it was done switching. The train did not come for 45 minutes, in which I caught a whole lot of Light Rails and chose these 3 clips to upload. Eventually I left to see if It was done switching and of course then it came so I went instead to Sampson St to catch it.

Metropolitan Transit System Trolley Light Rails stop at Harborside Station and pass through the South 28th Street Double Railroad Crossing on the MTS Trolley Bluec Line in San Diego, California. The close crossing is an ATSF 1940s to 1950s install with changes to its bells, gates, and gate mechs which used to be RACO Hydraulic. The far crossing is an MTS mid 2010s install with changes to the far signals bells.

Crossing Info
This crossing with the close signals owned by BNSF Railway and the far signals owned by Metropolitan Transit System (MTS) is an horn zone and bells ring through the whole activation.

Close Crossing (BNSF)
Right Shoulder Signal
Bell: NEG Electronic Bell
Lights: Two pairs of 8 inch RACO Incandescent Lights
Light Heads: Twompairs of 8x24 inch RACO Lights
Brackets: WRRS
Junction Box: WRRS
Gate Lights: RECO LEDs
Countrerweight Arms: Safetran
Mechanism: Safetran
Base: WRRS

Median Signal
Lights: One pairs of 8 inch RACO Incandescent Lights
Light Heads: One pairs of 8x24 inch RACO Lights
Brackets: WRRS
Junction Box: WRRS
Gate Lights: RECO LEDs
Countrerweight Arms: Safetran
Mechanism: Safetran
Base: WRRS

Left Shoulder Gateless Signal
Bell: General Signals Type 2 Electronic Bell
Lights: Two pairs of 8 inch RACO Incandescent Lights
Light Heads: Twompairs of 8x24 inch RACO Lights
Brackets: WRRS
Junction Box: WRRS
Base: WRRS

Median Gateless Signal
Lights: One pair of 8 inch RACO Incandescent Lights
Light Heads: One pair of 8x24 inch RACO Lights
Brackets: WRRS
Junction Box: WRRS
Base: WRRS

Far Crossing (MTS)
Right Shoulder Signal
Bell: Siemens/Safetran Type 3 Electrnic Bell - Medium Tone
Lights: Two pairs off 12 inch RECO LEDs
Light Heads: Two pairs of 12x24 inch Safetran Lights
Brackets: Safetran
Junction Box: Safetran
Gate Lights: NEG LEDs
Counterweight Arms: Safetran
Mechanism: US&S Modal 95
Base: Safetran

Median Signal
Lights: Two pairs off 12 inch RECO LEDs
Light Heads: Two pairs of 12x24 inch Safetran Lights
Brackets: Safetran
Junction Box: Safetran
Gate Lights: NEG LEDs
Counterweight Arms: Safetran
Mechanism: US&S Modal 95
Base: Safetran

Left Shoulder Signal
Cantilever: Progress Rail
Lights: Three Pairs of 12 inch RECO LEDs
Light Heads: Three Pairs of 12x24 inch Safetran lights
Brackets: Progress Rail
Junction Boxes: Progress Rail
Gated Mast
Bell: General Signals Type 2 Electronic Bell
Lights: One pairs off 12 inch RECO LEDs
Light Heads: One pairs of 12x24 inch Safetran Lights
Brackets: Safetran
Junction Box: Safetran
Gate Lights: NEG LEDs
Counterweight Arms: Safetran
Mechanism: US&S Modal 95
Base: Safetran

Far Median Signal
Bell: General Signals Type 2 Electronic Bell
Lights: Two pairs off 12 inch RECO LEDs
Light Heads: Two pairs of 12x24 inch Safetran Lights
Brackets: Safetran
Junction Box: Safetran
Gate Lights: NEG LEDs
Counterweight Arms: Safetran
Mechanism: US&S Modal 95
Base: Safetran

Camera & Equipment
iPhone 13 Pro
ANGLIFY Phone Tripod
Uniden BC125AT Scanner
