LISEC Complete Vertical Automated Insulating Glass Line With SUPER SPACER - 2500 X 3500 mm

Описание: Direct Link to Listing: http://exf.ac/b17

The loading zone at the inlet is designed to feed the washer in a timely manner. Using an 8-Brush washer and drying zone ensures cleanness of the single glass sheets before frame mounting and insulating glass assembly.

Final visual quality checks are done at the frame mounting station. The press finalizes this automated process before manual take off and secondary sealing.

LISEC Working direction: From left to right. Maximum glass production size 2500 x 3500 mm (98" x 138")

Consists Of The Following Equipment Components:

LISEC Infeed Conveyor

LISEC "VHW-25/6M" Vertical Washing Machine
Automatic 6-Brush Washing and drying system for glass panes with infinitely variable adjustment of the glass thicknesses. With LOW-e capability.

LISEC Outfeed Conveyor

LISEC "VSA-35/25" Assembly And Frame-Setting Station
Fully automated vertical station for the application of flexible spacer frames on glass sheets. After feeding in the glass sheet to the reference point, the auxiliary frame mounting stops automatically adjusts to the bottom and front vertical glass edge. The operating height of transport is 520 mm at a 6° incline. Minimum processing height is 180 mm with minimum processing length of 250 mm.

[2] LISEC Storage Sections

LISEC "FPS-36/25US" Gas Filling Press
Gas filling Robot for double and triplex units

LISEC "VFL-1D/25" Automatic Sealing Robot
Automatic sealing Robot VFL-1D can do triplex units. for maximal unit sizes of 2500 x 3500 mm

LISEC "DOS-1PSD" Mixing And Metering Station

LISEC "LBH" Extruder And Freezer
Refrigeration unit where the extruder gun (incandescent) is positioned at the end of the sealing process. An accessory of the automatic sealing robot

NOTE: IG line is in very good operating condition & Includes all pertinent infeed and outfeed conveyors as well as transport conveyors. Ready for immediate shipment.

NOTE: Price includes “Installation and Full Service Logistics” from Overseas Supplier to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door) in Melbourne, Australia, - Price does not include "Australian Import Duty (if applicable), VAT and Local Taxes. - Airline Ticket(s), Room and Board for Technician(s) will be invoiced separately.
