How To Build And Fly A Cartoon Cessna 182 Rc Plane At Home!

Описание: This cartoon style RC model plane is based on Cessna 182. I just squeeze it into a chubby plane. This model is quite unique, because this is the second model from the models that I ever made, that needs counter weight ballast on the tail. The first one is T-6A Texan II model. The ballast is quite heavy, around 200 gram, so recommend to put the battery on the tail so you don't have to add ballast and will save about 200 gram of weight. With 1200 gram the plane is quite fast but with 1000 gram I believe it will more enjoyable. But after all the plane is easy to control, just add aileron rudder mixing about 40% for smooth turning.

Download the plans here :
https://paper-replika.com/index.php/r...

Join this channel to get access to perks:
   / @juliusperdana


Specs with ballast (battery on the front) :
1. Wingspan 1200mm / 47.2 inches
2. Flying weight : 1200 grams/ 42.3 oz/ 2.64 lbs
3. Wing loading : 48.5 gram/dm2 - 15.9 oz/sq.ft.
4. Wing cube loading : 9.8 (Aerobatic)
5. Wing Area : 24.74 dm2 / 383 sq.in.
6. CG : Wing Spar

Specs without ballast (battery on the tail) :
1. Wingspan 1200mm / 47.2 inches
2. Flying weight : 1000 grams/ 35.3 oz/ 2.2 lbs
3. Wing loading : 40.4 gram/dm2 - 13.3 oz/sq.ft.
4. Wing cube loading : 8.1 (Trainer)
5. Wing Area : 24.74 dm2 / 383 sq.in.
6. CG : Wing Spar

Electronics
DXW 3536 1200kv Brushless motor
11x5 prop
40A-50A ESC
3-4S 2200mah Lipo Battery
4x 9 gram servo

Transmitter
Jumper T16 + BetaFPV Express LRS TX module
10 ch BetaFPV Express LRS RX

Materials :
1. 6mm Foamboard/ Depron/ Polyfoam
2. Bamboo Chopstik
3. 4mm Carbon Tube/ Bamboo
4. 0.5mm Mica Plastic
5. hot glue, UHU glue, CA glue, PVA glue
6. Packing tapes
7. Elastic band (1.5 meters/ 5 ft)
