Test flight of Hybrid Razor : 52.7km

Описание: This was test flight of Hybrid Razor that is best efficient flight of Razor.

At first, I modified Razor to pusher type for clean FPV.
   • Razor of Eachine, Modification to pusher type

But, the efficiency of flight was not so good and maximum flying distance could not over 30km by 2S1P.

In result, after hybrid conversion,
although relative wide solar wings, the efficiency of flight could not reach to that of small hybrid planes, Dart250G, Drift 877.

But, thanks to good motor & good efficiency of nose type motor,
the efficiency of hybrid Razor reached to that of hybrid Dart250G.

After re-modification to nose motor type,
the camera moved to bottom of fuselage as like U-glider.

So, FPV is forward downward direction.


If hybrid Razor be loaded by 2S2P li-ion batteries,
flying over 100 km would be not difficult one.



Thank you for watching ^^





Other video of Razor


Maiden flight of Razor
   • Maiden flight of Razor modified to pusher ...


Test flight
   • Boring test flight of Razor to check effic...


Modification of Razor to pusher type
   • Razor of Eachine, Modification to pusher type


Maiden flight of Razor
   • Maiden flight of Razor modified to pusher ...


Boring test flight of Razor to check efficiency and max. flying distance
   • Boring test flight of Razor to check effic...


Hybrid conversion of Pusher type Razor
   • Hybrid conversion of Razor , Maiden flight


New solar wing of Razor
   • Hybrid Razor got another solar wings ^^


Test of two solar wings of Hybrid Razor, meaningless
   • Test of two solar wings of Hybrid Razor, m...






Specification of Hybrid Razor
Wing span : 1200 mm
AUW including Li-ion 2S1P : 473 grams
added by hybrid conversion, 135 grams
motor : Xnova 2207 kv 2600
Propeller : 8 x 45
ESC : Emax lightning S 25A
Servos : default of PNP
Fpv camera : Caddx ant at bottom
Video transmitter : Eachine Nano V3
FC : Matek F722 mini se
LRS : Crossfire nano receiver
GPS rx : Beitian 220
DVR : Eachine DVR
Battery : Li-ion 3500mah 2S1P,
Solar cells : 110 small solar cells of solarealdrone.com
