Short test flight of Baby AR Wing pro , 86km, motor change

Описание: This is short test flight of Baby AR wing pro that was loaded with 2S5P and was changed motor to 2204.5 kv3500.

3 motors 2203.5 kv3300, 2105 kv3600, 2204.5 kv3500 are similar size ones, but slightly different kv ones.

At this time, for more efficient result, mid kv one was selected.

Of course, for more efficient flight,
the cruise throttle was decreased from 1400 to 1350,
so average speed was slightly decreased,
but, efficiency of flight was slightly improved.

This reduction of throttle use rather than change of motor is probably main cause of improved efficiency.


Baby AR wing pro repeat 3 waypoints flight many times automatically.

This rough efficiency was 84mah/km,
better than previous 94 mah/km

The maximum flying distance of 2S5P, 20500mah could be estimated to about 244km.


Thanks.


0:30 flight report
0:41 loaded 2S5P cellular phone batteries
1:00 Summery of test flight
1:30 planned mission
1:40 autolaunching. overhead backward powerful launching
1:57 DVR recorded shortly edited one turn of 3 waypoints



unedited DVR recorded video of this flight
   • Short test flight of Baby AR Wing pro , 86...


Heaviest Baby AR Wing Pro : 2S5P loaded, 205 km, longest test flight
   • Heaviest Baby AR Wing Pro : 2S5P loaded, 2...

Heaviest Baby AR Wing Pro : 2S5P loaded, 205 km, longest test flight
Unedited DVR recorded video
   • Heaviest Baby AR Wing Pro : 2S5P loaded, 2...

2S4P 191km 3 hour flight
   • Baby AR Wing pro : long test flight, 191km...

2S4P 191km 3 hour flight, Unedited DVR recorded
   • Baby AR Wing pro :long test flight, 191km,...

Baby AR wing pro : completion, maiden & long test flight, 101km
   • Baby AR wing pro : completion, maiden & lo...



Summery of short test flight

PM 3;00 start mild windy
flying distance : 86km
postcharging of 2S5P, LiHV : 7230mah
Rough efficiency of 2S5P flight : 84mah / km
Estimated max. flying distance of 2S5P
: 20500mah / 84mah /km
= about 244km



Specification of Baby AR wing ​

wing span : 682mm

Empty weight : 213 grams

motor : 2204.5 kv 3500

prop. : 5.1 inch

ESC : Littlebee 30A

Power : 2S5P 20500mah
10x LiVH 4100mah cellular phone batteries

Servo : ES 9052 MD of EMAX

FC : Mateksys F405TE

Firmware : iNav 6.1.1

Camera : baby Ratal of Caddx

Video transmitter : JHEMCU VTX20-600
