FactoryTalk View Studio Site Edition | RSlinx Connection Status Animation | Batching PLC Day-13

Описание: How to monitor the connection status in FactoryTalk Linx using a simple method in FactoryTalk View Studio Site Edition.

An effective way to check to see if your communications are live & if not then you can trigger an HMI animation to alert someone.

This is day 13 of the Batching Station plc training that we are doing, it is important to note that we have to slow down & pay attention to detail to really learn & care about our future growth.

It is up t us to learn, implement, & succeed so this is why we try to teach plc & HMI controls.

Here are the previous video leading up to this one:
Video 1:    • Creating A Studio 5000 PLC Program From Sc...
Video 2:    • Adding I/O Into A Studio 5000 PLC Program ...
Video 3:    • Studio 5000 Tag Structure For I/O | Downlo...
Video 4:    • Starting a FactoryTalk View Studio Site Ed...
Video 5:    • FactoryTalk View Studio Site Edition Quick...
Video 6:    • FactoryTalk Video Studio Site Edition Clie...
Video 7:    • Designing Tanks & Valves in A FactoryTalk ...
Video 8:    • FactoryTalk View Studio Site Edition | Des...
Video 9:    • FactoryTalk View Studio Site Edition | Tan...
Video 10:    • FactoryTalk View Studio Site Edition | Pro...
Video 11:    • FactoryTalk View Studio Site Edition | Bui...
Video 12:    • FactoryTalk View Studio Site Edition | Mak...

Video Content:
0:00 - Quick Intro
0:40 - Adding the text for the connection status
1:25 - Adding the HMI animation to the text image if FactoryTalk Linx drops
2:30 - Discussing @Present tag for the FactoryTalk View shortcut
3:15 - Testing the communication drop of the FTView HMI shortcut
3:45 - Showing the link status dro & the HMI animation working
4:20 - Adding the System/Blink to the HMI animation expression
6:00 - Fixing the expression syntax to properly work for the animation
8:30 - Testing the communication drop for the blinking status
10:00 - Recommended Video for you

I hope it helped.

Thank you for watching the video.

Learn, Implement, Succeed
