FactoryTalk View Studio Site Edition | Making A Header For An HMI Client | Batching PLC Day-12

Описание: In FactoryTalk View Studio Site Edition you can have standard headers for each screen or one default HMI header for the whole HMI application.

In fact, using the way we are showing in this video, you can use a separate header as a screen then call it up in different sections of the HMI application.

This is the twelve video in this series so we are finally getting to stages where we can launch the HMI client. This batching station project shows everything built from scratch for those that are willing to learn video per video.

In this world of information, it is important to note that we have to slow down & pay attention to detail to really learn & care about our future.

Here are the previous video leading up to this one:
Video 1:    • Creating A Studio 5000 PLC Program From Sc...
Video 2:    • Adding I/O Into A Studio 5000 PLC Program ...
Video 3:    • Studio 5000 Tag Structure For I/O | Downlo...
Video 4:    • Starting a FactoryTalk View Studio Site Ed...
Video 5:    • FactoryTalk View Studio Site Edition Quick...
Video 6:    • FactoryTalk Video Studio Site Edition Clie...
Video 7:    • Designing Tanks & Valves in A FactoryTalk ...
Video 8:    • FactoryTalk View Studio Site Edition | Des...
Video 9:    • FactoryTalk View Studio Site Edition | Tan...
Video 10:    • FactoryTalk View Studio Site Edition | Pro...
Video 11:    • FactoryTalk View Studio Site Edition | Bui...

Video Content:
0:00 - Quick Intro
1:50 - Start making the new display for the HMI header
2:40 - Setting the wide & height of the HMI client header
6:09 - Adding the Date & Time readout on the HMI client header display
9:05 - Adding HMI screen navigation buttons to the HMI header
12:00 - Aligning the navigation buttons on the HMI header
14:20 - Adding the HMI application name to the header display
17:30 - Recommended videos for you

I hope it helped.

Thank you for watching the video.

Learn, Implement, Succeed
