How to Terminate an RJ45 — Ethernet Crimping Tutorial (Cat6)
Автор: Wire Ninjas
Загружено: 2026-01-30
Просмотров: 22
Описание:
RJ45 termination done right. In this tutorial, we show how to terminate a pass-through RJ45 connector on Cat6/Cat6A Ethernet cable using the T568B wiring standard; clean prep, correct order, proper seating, and a solid crimp.
This is the same process we use on real structured cabling jobs to prevent link drops, slow speeds, and call-backs.
What you’ll learn:
• Pass-through RJ45 workflow (start → finish)
• T568B wire order + alignment tips
• Strip length + jacket support (strain relief matters)
• Clean cut + proper crimp technique
• Quick checks to confirm you did it right
Wire Ninjas standard: No shortcuts. No guesswork. Fully documented.
Subscribe for structured cabling, racks, Wi-Fi design, cameras, and clean installs.
Business / consultations: [email protected]
New Jersey based | Serving clients Nationwide
#rj45, #termination ,#lowvoltage , #datacabling ,#networkcabling ,#rack , #wireninjas , #structuredcabling
