Punchdown Keystone Termination (Silent Visual Demo) — No Voiceover
Автор: Wire Ninjas
Загружено: 2026-02-13
Просмотров: 4
Описание:
How to terminate a Cat6 punchdown keystone jack using a 110 punchdown tool. We follow the keystone’s T568B wiring map, keep twists tight, seat conductors cleanly, punch down with the cutting blade facing the excess, and close it up for a clean finished termination.
What you’ll see:
• Full punchdown keystone workflow (start → finish)
• T568B color map setup
• Strip length + minimal untwist
• Seating conductors into channels
• Punchdown technique + cutting blade direction
• Quick visual checks to confirm it’s correct
Looking for the full narrated tutorial? Check the updated upload on our channel.
Wire Ninjas standard: No shortcuts. No guesswork. Fully documented.
Subscribe for structured cabling, racks, Wi-Fi design, cameras, and clean installs.
Business / consultations: [email protected]
New Jersey based | Serving clients nationwide
