SAP S/4 Hana-AM Lec.4 Create Equipement (Machine, PRT, Fleet Object) assign to Functional Locations.

Описание: Lec. 4 – Create Equipment & Assign to Functional Location (SAP S/4HANA AM)
1. Key Concepts Recap

Functional Location (FL):
A fixed place where maintenance is performed (e.g., Plant → Area → Line).

Equipment:
An individual physical object that can be installed, dismantled, or moved.

Relationship:

Functional Location = “Where”

Equipment = “What”

2. Types of Equipment in SAP AM
A. Machine Equipment

Production machines, pumps, motors, compressors

Has serial number, maintenance history

B. PRT (Production Resource/Tool)

Tools, gauges, molds, measuring devices

Often linked to production orders & calibration plans

C. Fleet Object

Vehicles: trucks, forklifts, cranes

Uses Fleet Management features (counter = mileage/hours)

3. Transaction Codes
Purpose T-Code
Create Equipment IE01
Change Equipment IE02
Display Equipment IE03
Create Functional Location IL01
Assign Equipment to FL IE02 / IE01
4. Create Equipment (IE01)
Step-by-Step

Execute T-Code: IE01

Select Equipment Category

M – Machine

P – PRT

F – Fleet Object

Enter Data in Tabs

Important Tabs & Fields
A. General Data

Description

Object Type

Manufacturer

Model

Serial Number

B. Location Tab

Functional Location (if already exists)

Plant

Location

Room

➡️ This is where equipment is assigned to FL

C. Organization Data

Maintenance Plant

Planning Plant

Company Code

D. Structure Tab

Shows installed position

FL–Equipment hierarchy

E. PRT-Specific (PRT Equipment)

Calibration required

Measuring unit

Usage type

F. Fleet-Specific (Fleet Object)

License plate

Vehicle type

Counter (Mileage / Hours)

5. Assign Equipment to Functional Location
Option 1: During Creation

Enter Functional Location in Location tab of IE01

Equipment is installed automatically

Option 2: After Creation

Go to IE02

Open Location tab

Enter Functional Location

Save

6. Installation & Dismantling Logic

Equipment can be moved

History is recorded automatically

Functional location remains fixed

T-Codes:

Install: IE01 / IE02

Dismantle: IE02

7. Example Scenario

Functional Location:
PL01-PRD-L01 (Production Line 1)

Equipment:

Machine: CNC Milling Machine

PRT: Torque Wrench

Fleet: Forklift FL-01

All three:

Created via IE01

Assigned to same FL

Have separate maintenance histories

8. Business Benefits

Accurate maintenance planning

Equipment history tracking

Better asset utilization

Compliance & calibration control (PRT)

Fleet cost monitoring

9. Exam / Interview Points

Equipment is mobile, Functional Location is fixed

One FL can have multiple equipment

Equipment can be installed at only one FL at a time

PRT & Fleet Objects are special equipment categories
