Long Distance 120x Zoom Day Night Camera with laser IR Night Vision Surveillance +Thermal Infrared
Автор: Ascendent Technology
Загружено: 2014-07-24
Просмотров: 17100
Описание:
Long Range Day Night surveillance visible/NIR Infrared PTZ CCTV Security Camera Super Optical Zoom 120x 16~2000mm HD CMOS IP ONVIF Camera for perimeter security, coastal surveillance with FLIR Therrmal Infrared, Gyro Stabilized Pan tilt, ZLID IR laser Illumination designed for Slew to Cue auto tracking with Radar and AIS systems.
Modle: SIGMA-3000M-2000-HD-CT-750 Ascendent Tecchnology
Key Features:
• Turn-key extreme long-range electro-optic surveillance system
• Multi-sensor, visible, cooled thermal, and IR illumination
• Cooled thermal: Up to 23km of human detection (40km vehicle)
• Geranium lens for thermal 50/250mm, 100/500mm, 150/750mm
• IP HD 1/3” Progressive Scan CMOS day/night ONVIF S Sensor
• 16-2000mm IR corrected motorized zoom lens with fog filter
• Colour by day, monochrome by night and 24/7 thermal
• Up to 5km ZLID IR illumination (syncs with zoom lens)
• Micro-Step technology for accurate pan/tilt better than 0.01°
• 360° continuous rotation with tilt functions and presets
• Rugged military grade IP 66 anti-corrosive treated enclosure
• Extreme weather -50°C to +60°C with defroster & wiper
• Options: Range finder, GPS, Slew-to-Cue, & auto tracking
24/7 Day/Night Surveillance
The SIG-3000M-2000-CT is designed by Infiniti specifically for critical infrastructure and perimeter protection. It offers a compelling alternative to the conventional single-camera system. The dual sensor payload enables the Sigma Series to provide images in virtually any environment from heavy fog to complete darkness. The cooled thermal imager provides long-range, wide-angle detection allowing proper assessment of potential hazards and threats at great distances with a high level of accuracy. The high-resolution visible camera provides superior clarity over thermal imaging and yields high detail to identify threats and trespassers even in complete darkness.
Visible Optical Zoom Camera
The Sigma Series PTZ boasts a 1/2” high-resolution visible camera that renders superb detail color images by day and clean, crisp monochrome images at night. This camera has a powerful 16-2000mm motorized zoom lens for FOV’s ranging from 22° to 0.14° degrees and zoom ratio of 120X.
Active IR ZLID Laser Illumination
Many laser illuminators only light the center of the screen and act as a spot beam that over-exposes the center of the image and leaves the edges dark. Infiniti’s laser has up to a 0.35° to 19° (43X) resulting in an illuminated scene that matches the FOV of the camera. Infiniti’s ZLID (Zoom Laser IR Diodes) technology synchronizes IR intensity and area illumination with a motorized zoom lens for outstanding active IR performance, eliminating over-exposure, washout, and hot-spots for performance at distances ranging from 150m up to 5km (16,400ft) in complete darkness.
Pan-Tilt Resolver
The heavy-duty PTZ driver is designed for extreme performance in the most demanding applications. It implements brushless motor technology for endless 360° panning and Micro-Step technology for precise (0.01°) pan and tilt positioning. Advanced features, such as preset and auto-cruise, will complement almost any existing equipment by means of Pelco-D and Pelco-P protocols.
Intuitive and User Friendly
Although the SIG-3000M-2000-CT is an extremely sophisticated piece of equipment, it is operated by an intuitive, user friendly interface with multiple control options such as touch screen and mouse. It can also be controlled by a 3-axis joystick and operated by any individual without prior training. Additionally, the optional Image Stabilizer (IS) and fog filter helps eliminate the effects of vibration and waves giving the Sigma similar performance of a gyro-stabilized system at a fraction of the cost.
Rugged and Robust
The SIG-3000M-2000-CT is comprised of military grade, precision engineered components and manufactured using unique processes to offer absolute performance. It integrates a military style connector to supply power, video, and communication over a single cable. The Sigma also does not require a junction box or external electronics of any kind, increasing reliability and the amount of time required to install the system.
Remote Connectivity
View all of your cameras and control them through the internet in real-time from anywhere in the world using Infiniti Remote Management Software (ARMS) on your laptop, iPhone, or Android device.
Sigma Thermal
The integrated thermal detector Focal Plane Array (FPA) is based on INsB cooled core that comes in a 640x480 resolution, with sensitivity of 25MK. Precision engineered germanium lenses that offer a dual FoV up to 150 / 750mm (at 3.75° to 0.75°) for razor sharp images that maintain a low f-stop for real-time performance without lag and latency to provide extreme long-range performance and excellent image quality.
Website: www.ascendentgroup.com
Email: [email protected]
Skype: tim.ascendent
