Best Long Range Thermal PTZ Camera Thermal IR Infrared PTZ 1-40km Night Alternative to FLIR HRC PTZ

Описание: Vega PTZ thermal camera alternative FLIR HRC & HDC camera 850mm 22x Cooled thermal infrared PTZ Camera System designed for long range day night 24/7 surveillance. www.infinitioptics.com

The Vega is a revolutionary multi-sensor PTZ camera boasting a long-range 135X visible day/night camera, long-range thermal infrared zoom, and optional ZLID IR laser illumination with LRF. This multi-sensor payload enables the Vega to provide high resolution imaging in virtually any environment from heavy fog to complete darkness. Designed for accurate positioning of weapons systems, the pan/tilt unit meets and exceeds MIL-STD-810F military ratings for shock, vibration, temperature and dust/water ingression. This makes the Vega the ultimate long-range camera system for 24/7 situational awareness and long distance recognition and identification of targets.


www.infininitioptics.com

Key Features:
›› Ultra Long-Range Military Grade Multi-Sensor PTZ Surveillance
›› Day/Night 1080p HD IP ONVIF 1/2.8" CMOS Sensor
›› 135x 15.5–2075mm HD IR-Corrected Zoom Lens
›› Autofocus, Motorized Fog Filter & Temperature compensation
›› Image Enhancements: WDR, HLC, EIS, 3DNR, Fog/Haze
›› 1024x1280 or 640×480 15μm InSb Cooled Thermal Imager
›› 46–1075 mm Continuous Zoom Auto-Focus Thermal Lens
›› 18–0.55° Horizontal Field of View for a 22X Thermal Zoom
›› Up to 27km of Human Detection and 43km of Vehicle Detection*
›› 20,000+ Hour Lifetime Cyrogenic Cooler
›› MIL-STD-810F, -50°–+65°C and IP66/67 with Anti-Corrosion
›› Elliptical Synchronous Drive, Gyro-Stabilized Heavy Duty Pan/Tilt
›› Endless 360° Rotation Pan/Tilt with Speeds from 0.001–110°/s
›› 0.00009° Resolution with Zero Backlash
›› 1535nm 23km Rated LRF with 50~250mm Range Accuracy
using InGaAs Detector

Infiniti’s cooled thermal cameras let you see further than any
other night vision technology, using heat rather than light to
see objects. This cooled thermal imaging camera is equipped
with a Mid-Wave Infrared (MWIR), cooled Indium Animonide
(InSb) detector, producing ultra-sharp thermal images of 640×480
pixels. This will satisfy users that want to see the smallest of details and demand the best possible image quality. It allows the user to see more detail and detect smaller objects from a further distance. Coupled with a high sensitivity sensor, and leading germanium optics, this camera offers extremeeme long-range performance and excellent image quality.

Cooled InSb Thermal Imager
The Vega contains a high sensitivity 15μm cooled InSb sensor
with a resolution of 640×480 and an ultra-long cooler lifetime of
20,000 hours MTBF. The cooled sensor is able to detect differences in temperature as small as ±0.02°C. This provides more detail for tracking of targets at extreme ranges in total darkness and through most obscurants. 22X Continuous Zoom Germanium Lens

Long Range 135X Zoom Lens
The Vega comes equipped with a precision engineered 15.5–2075mm IR-corrected zoom lens with motorized HD doubler, offering an incredible 135X zoom range from 20.6° through to a very narrow 0.15° FOV when paired with the 1/2.8" sensor. That's equivalent to a “full-frame” DSLR camera using a 13,500mm lens. Infiniti’s zoom optics are built with the highest quality Japanese fluorite ELD low dispersion glass, and the integrated rapid auto focus allows long range recognition and identification of targets without operator intervention. The lens also incorporates a motorized fog filter that is used with the camera’s monochrome mode and de-haze image processing to see through fog, smoke, smog and haze that render standard optical cameras unusable. Infiniti’s HD Zoom camera is a perfect synergy between precision craftsmanship, state of the art sensor hardware and the latest image processing for unparalleled range and performance.

Active IR ZLID Laser Illuminator
IR illumination allows for detailed video when there isn't enough
natural light, however for long-range IR illumination a laser is needed. Many laser illuminators overexpose the center of the screen and leave the edges dark. Infiniti’s ZLID (Zoom Laser IR Diode) technology synchronizes the IR intensity and area illumination with the zoom lens for outstanding active IR performance, eliminating over-exposure, washout, and hot-spots for clear images in complete darkness
