SM-HBS500SAM Steelmaster Semi Auto Double Mitre Bandsaw. 500mm x 305mm Capacity. Semi Auto

Описание: SM-HBS500SAM Steelmaster Semi Auto Double Mitre Bandsaw. 500mm x 305mm Capacity. Semi Auto Hydraulic Vice Clamp, Blade Breakage, Tungsten Blade Guides, Work light, CE Compliant. 415V

Description
This large capacity semi automatic full featured Metal-Cutting Bandsaw includes large cutting capacity, a swivel head to cut miters from -45 degrees to +60 degrees, hydraulic clamping, variable speed control, hydraulic feed control and built-in coolant system. If you're looking for something in this size range, you'll have a tough time finding a better metal-cutting band saw with these features and at this price anywhere else. Metalworking production shops should take a good look at this!

Features
❚semi automatic operation
❚hydraulic vice clamping
❚double mitre cutting from -45 ~ +˚60˚
❚auto saw blade breakage power cut off
❚durable 27 mm wide blade
❚strong construction design
❚tungsten carbide blade guides
❚coolant system and twin swarf brushes for increased efficiency
❚auto cut-off switch
❚variable hydraulic downfeed
❚centralised control panel
❚work light fitted standard
❚blade break detection system
❚twin support arms
❚1.5 kw 415 Volt operation
❚variable speed 15-84 MPM
❚CE compliant

Technical Data Snap-Shot
❚500mm x 305mm capacity at 90 degrees
❚305mm x 305mm capacity at 45 degrees
❚200mm x 160mm capacity at 60 degrees
❚305mm round capacity at 90 degrees
❚275mm capacity at 45 degrees
❚200mm capacity at 60 degrees
❚0~ 60 degree mitre cutting
❚doouble mitre vice
❚3820mm x 27mm x 0.9mm blade capacity
❚motor capacity - 1.5Kw x 415Volt
❚shipping dimensions - 2160mm x 1010mm x 1220mm pack
❚weight: 620kg

Recommended Add On Accessories
❚15+0149 - 3820 x 27 x 5/8 Vari -Tooth Rontgen German Quality Bandsaw Blade.
❚15+0082 - 3820 x 27 x 6/10 Vari -Tooth Rontgen German Quality Bandsaw Blade.
❚15+0083 - 3820 x 27 x 10/14 Vari -Tooth Rontgen German Quality Bandsaw Blade.
❚15+0265 - Roller Conveyor 3000mm Long x 450mm Wide. 60 mm Rollers, Legs Sold Separate.
❚15+0266 - Roller Conveyor Legs. To Suit 450mm Wide x 505mm ~ 800mm Adjustable Height.
❚15+0287 - Heavy Duty Roller Assembly 520mm Wide Complete with Bearing and Housing Assemblies - Sold Each
❚11+0707 – Alfra Rotabest - Magnetic Swarf Remover
❚15+0187 - Coolant Mineral Based XDP-1000 5Lt Drum Metalium - Soluble - 20:1 Mix
