SM-KD7SS. Steelmaster Turret Type Mill, Horizontal Arbor, 1600mm x 360mm Table,

Описание: SM-KD7SS. Steelmaster Turret Type Mill, Horizontal Arbor, 1600mm x 360mm Table, 40/ 50 International Spindle Mounts, Servo Drive, Power Draw Bar & 3 Axis DRO - 415Volt

Description
This Mill is made with uncompromising quality Hardened and ground table, chromed quill & Turcite coated ways mean built-in durability for years of service. With a large 127mm quill travel standard and power draw bar fitted. Check out the capacities, features & specifications below! This is the machine to have for years of accurate, trouble-free operation.
Fitted with 3 axis digital read out. two axis table feed, power knee, variable speed head, quill feed all combine to serve you well.

Features
❚ large 127mm spindle travel standard
❚ Taiwanese engineered and Q&A
❚ 3 axis DRO fitted standard
❚ ergonomic control panel offering total control of all axis operations including joystick controls
❚ infinitely variable speed drive head with digital display
❚ long table travel (1300mm) and large table set-up area
❚ all manual operating handles located at the front of the machine
❚ unique horizontal milling arbor
❚ power draw bar fitted standard
❚ ballscrew servodrive on X / Y
❚ Taiwanese head and quality Meehanite cast frame
❚ solid, precise cross table with ground surface
❚ precisely ground carriage guides with adjustable dovetail guides
❚ head swivels to left and to right
❚ fine feed on spindle
❚ cutter head with honed sleeve support
❚ chrome-plated sleeve with extremely long cutting stroke
❚ large spindle bearings guarantee stability during milling
❚ guaranteed true run out on spindle taper 0.01 mm
❚ SM-KD7SS spindle speed controls operated via control panel

Automatic sleeve stroke
❚ spindle with right or left-handed rotation function
❚ cutter head with reduction gear for high torque

Technical Data - Snap Shot
❚table size - 1600mm x 360mm
❚X / Y / Z travel - 1050mm / 320mm / 440mm
❚spindle quill travel - 127mm
❚holding fixture - ISO / ISO-50 H, ISO-40 V
❚vertical speeds - 50 ~ 4000 - variable
❚horizontal speeds - 60 ~ 1800 - variable
❚spindle to table distance 200 - 650mm
❚motor capacity - 5.5Kw
❚shipping dimensions - 2400mm x 2100mm x 2250mm
❚approx weight: 2550kg

Includes
❚ 3 Axis digital readout system
❚ Auto lube system
❚ 2 x Axis power-feed
❚ safety cutter guard
❚ swarf tray
❚ coolant system
❚ LED lamp
❚ tool box and operation manual
