Vortex 250 Pro - Part2 Setup and OSD Settings Walkthrough | RCSchim

Описание: You see almost in real time how easy you setup the radio (ok I had some minor issues with my receiver) and you hear the sound of victory (Imperial March after TX Setup completed) and I show all the menu options. Really straight forward - most items are self explanatory.
also check out Part1: https://goo.gl/Zh4kyo

Menu stucture:
Vortex Menu___________________
►OSD Setup...
Landscape (ezOSD | AirRace | HUD | Game)
Margins (Normal | Safe | HD)
Pseudo (your Callsign)
Units
Telemetry
Pack Capacity (important for proper mah based battery warning!)
Beeper Frequ.
Startup Tones (Simple, Imperial March or Super Mario!)
White Level / Gray Level (Font color)
Alarms Setup... (Battery mah, mV, UHF Stats RSSI, Flight Time)
_______________________________
►LED Setup...
LED Mode (Fixed, Blink)
you can have it reflect your throttle input and change intensity, blink frequency or color if you fly fast!
_______________________________
►Video Tx...
Frequency
Band
Channel
Power (Auto, Low, High) where low~250mw and high ~ 350mw
[GRAPHICAL Overview of channels - nice!]
_______________________________
►Game Setup...
...explained below
_______________________________
►FlightControl...
3 Profiles available (so you can have 3 presets and choose with which to fly (eg. different styles, battery weight...)
you can fine tune your PIDs here but you can also load pretuned settings from pilots that really understand what they do :-)
►►►ATTENTION: if you update FC firmware to current versions - PIDs from Pros wont work well anymore - because PIDs influence changed...
_______________________________
►Pro-tuning...
there are 12 Tunes from MetalDanny, UmmaGawd,... only to name a few)
_______________________________
►Diagnostics (Motor Tests!)
►Run TX Wizard (you also get there by long pressing the LED button!)


Game mode?
They use the Barometer to give you more score if you fly low. Since you have no GPS the mode doesnt know how long one lap on your track takes - so you fly a few rounds and enter the average lap lenght in here. No accurate - but can be fun if you wanna "low flying high scoring challenge" here :-)


►Quick Tipps:
LED Board button
Press 2sec to change VTX BAND
Press 5sec to enther TX Setup Wizard

Arm Motors Throttle=0, YAW=right
Disarm Throttle=0, YAW=left
Enter OSD Throttle=0, YAW=left (while Motors are disarmed)
(if you cant arm or dont get into the menu: try trimming yaw more to right or left - your stick "servo-way" is not 100% - set rates on your radio to 100% and repeat the TX Wizard!)

►►GPS Support?
Immersion told me, if you use a "supported" GPS ezOSD will use it and show speed and distance. Anyone already tried this?
I'll see if I can get more info on this...

►Links:
ImmersionRC Offical Page: http://goo.gl/GgJLZE
Quick Manual: https://goo.gl/NHE22X
Huge RCGroups Thread: http://goo.gl/qM41K0


►Tech Specs:
Size (diagonal): 250mm (275mm option for 6" Props)
Frame: 2mm CF, with 15x Aluminium Standoffs
Arms: 4mm Flat CF
Motors: Custom 2204-2300kV, 3mm Shaft
ESC: 20/22A EzESC, OneShot125, rotorSENSE
Flight Controller: STM32F303 based ('F3')
OSD : Full Graphic
VideoTX Power: 250-350mw

BlackBox: 2MB Included
Rx Support: Native CPPM, S-Bus, Spektrum, XBus, SumD, SumH
Rx Selection: Fully Automatic
Case: Foam or Zipper case options at order time
Camera Mount: GoPro 3/4, mount included
USB Port: Through-Hole (Much more robust)
LED Board: v2, more robust
Lost Model Beeper: Yes... MUCH louder
Standoffs: Metal (all of them)
FlightCam: 700TVL CMOS v2
weight: 671gr (with gopro+ 1300mah 4s)
451gr all except hd cam and batt)
