Side table alignment jig for Robland X-31

Описание: Robland X-31 is a five function woodworking machine.
This machine has a sliding side table that is supposed to be running in parallel with the circular saw blade.
Unfortunately the adjustment of that side table is very difficult without a dedicated jig.
I am making such a jig to help a friend out of the forest.
The video has a section where the spoken language is Finnish. Please, utilize the hand written subtitles in case You cannot understand the language and want to know what we are talking about.

In this video I am using:
Weiler Matador SV (1972) Lathe
Schaublin SV-51 (1955) Milling machine
Solberga (1975) Drill press

The technical drawings are available at my Google drive:
https://drive.google.com/drive/folder...

Chapters:
0:00:00 Intro
0:03:52 Preparing dovetail bolt material
0:08:05 Roughing the bolt
0:10:57 Finishing bolt diameter
0:12:33 Preparing the bolt for threading
0:15:37 Set up lathe for threading
0:23:12 Single point threading the bolt
0:31:29 Milling the dovetail
0:34:59 Parting the bolts off from the material
0:37:39 Slitting saw exploded
0:39:48 Dialling in the table plate material
0:42:33 Milling and drilling the table plate
0:44:11 De-burring, reaming and threading the table plate
0:49:39 Milling and drilling the rail support
0:56:26 Marking and cutting off excess material
0:58:09 Finalizing the outlines and holes
1:00:58 Making threads to the rail support
1:02:19 Slitting the rail support
1:08:57 Visiting Kari's workshop
1:18:04 Photo album, conclusion and Bye

The video is suitable for the hearing impaired and persons who have difficulties in understanding my spoken English.
The video has hand written subtitles in English, German and Finnish languages.
