Measurement of A.C. Signal by using C.R.O | EREE | SOET | BGSBU
Автор: STEM Xplorers
Загружено: 2017-09-17
Просмотров: 1682
Описание:
• Connect the output of the function generator directly to channel 1 of the oscilloscope.
• Set the amplitude of the wave at 10 V and the frequency at 1 kHz.
Select sinusoidal wave shape.
• Sketch the wave shape observed on the oscilloscope. Determine the time period of the wave and calculate the frequency.
• Measure the A.C. voltage.
