Описание: • The Fourier series is concerned with periodic waves. The periodic wave may be rectangular, triangular, saw tooth or any other periodic form(single valued).


• Here I will also call this periodic wave as signal wave.Any periodic signal wave can be represented as a sum of a series of sinusoidal waves of different frequencies and amplitudes.


• Otherwise we can also say that a series of sinusoidal waves of different frequencies and amplitudes add up to give a periodic wave of non-sinusoidal form.


• Every periodic wave has a Time period(T) which is one complete cycle. The whole signal is the repetition of this period. Frequency (N) of the wave is the number of complete cycles in one second.

clearly N = 1 / T


• Observe the general Fourier series, it has a component (a1 sin wt), this sinusoid has the same frequency as the actual signal wave and it is called the fundamental component.


• The next component is (a2 sin 2wt), its frequency is twice that of fundamental (or original signal wave), this sinusoid is called second harmonic. So also the third, fourth etc.


• As an example if the fundamental wave has a frequency of 60 Hz, then the frequency of second harmonic is 120 (2* 60) Hz, third harmonic 180 Hz, 9th harmonic will be 540 Hz etc. The frequency of nth harmonic is (n.60).
