NEW ACCURL CNC Servo Turret Punching Machine MAX SF 30T with Sheets 1500x3000mm

Описание: The Perfect CNC Turret Punching Machine
HIGH PERFORMANCE

With Accurl 30 or 50 tons high speed servo punching machines head, sheet dimensions 3000 x 1500 mm and rotation axis for all tools, the MAX-SF is the perfect CNC turret punching machine. The large fully-brushed sheet support tables and the standard repositioning cylinders, allow for standard sheet sizes to be processed easily.

FLEXIBILITY IN MULTI-TOOLS
ACCURL®MAX-SF Series Servo CNC Punch Press Machine is the newly developed Multi Index Tools Turret Punch Press equipped with advanced Servo Hydraulic System, introduced by Tailift’s professional R&D and production teams who have been dedicated to machineries for decades. Accurl MAX SF Series CNC Punching machines provides the fastest, flexible and reliable punch press satisfying your expectation of fast and precise sheet metal works.

Advanced Servo Hydraulic System
●Advanced German made Schneider Hydraulic Servo system with pressure valve to precisely control the speed, volume and pressure of oil flow.
●To control the RAM stroke distance on both ends, hence the height and depth of each punch becomes programmable with 0.1mm accuracy.
●Uniquely designed Machine structure ensures less preventive maintenance.

Complex Multi-Tools Auto Index Technology
●Synchronized dual servo motors for controlling the auto index functions.
●2 D Auto Index Stations for Multi Tools, either 3 B or 8 A.
●Capable of indexing each individual tool within the 3B and 8A Multi Tool set.
●24 various size stations including 4 Auto Index stations Multi Tools.Therefore, a total of 24 to 52 tools can be employed.
●Capable of running wheel, marking, grooving and forming Tooling.


Standard Equipments
●Accurl Direct Drive servo punch system
●Fanuc CNC and high precision absolute encoder, dynamic, brushless alfa series servo motors
●3 automatic repositioning clamps and loading switches.
●FANUC Series Oi-PO CNC Control System
●Aluminum workholder
●Tool lubricating system (Airblow).
●Free standing control panel.
●Control with foot pedal.
●Tools stuck safety system
●1 software (Lantek or RADAN software).
●24 or 42 turret stations
●Digital oil temperature indicator.
●Software for using wheel and forming tools.
●Sheet jumping switches
●Scrap box.
●Chain protection around the machine (safety system).
