B Decking Buyers Guide [Pricing, Dimensions, Types, Gauges, Finishes, Uses, Lead Times]

Описание: Everything that you need to know about B Decking. In this video we cover HSB-36 which stands for high strength B Deck at 36". This B Deck video will answer all of your questions from pricing and cost, availability, and ordering information.

If you need to purchase B Decking we have it in stock for immediate delivery throughout the country.

In this B Deck video we will cover:
00:06 What is B Deck?
00:16 B Deck dimensions
00:26 What are the types of B Deck?
00:46 B Deck side laps
01:21 Table Of Contents
01:42 What are the uses of B decking?
02:44 What are the available finishes for B deck?
03:43 What gauge is b metal decking?
03:57 What's the price of B decking?
04:14 How long does it take to get B decking?
04:24 What lengths are available in B Deck?
04:38 How do I order B Deck?


Visit Our Website:
https://www.metaldeck.com/

B Decking:
https://www.metaldeck.com/verco-roof-...

HSB-36
https://www.metaldeck.com/b-deck-verc...


What is B Deck?
Type B Deck is the most common structural metal decking in the industry. It is an ideal structural substrate on short to medium span conditions that range from three feet to ten feet in distance. B Deck is lightweight, strong, economical, and easy to install. The panel in the image below is 1.5” deep and 36” wide. It also has 6 (6” wide) ribs with a male and female leg to create an interlocking sidelap.

Types of B Decking
Type B-Deck is manufactured into Type B Roof Deck and Type B Floor Deck.
Both types have identical dimensions and are manufactured with different sidelap connections. The only difference between them is the Formlok embossment pattern on the floor deck, which the concrete adheres to.

B Roof Deck
B Roof Deck is a smooth non-composite structural metal roof deck panel. It provides diaphragm shear and vertical load capacity to support the rigid board insulation and built-up roofing. It is produced by different manufacturers, with different sidelap attachments.

HSB-36
HSB-36 stands for High Shear B Deck @ 36" Wide. It has a standard male-female interlocking sidelap. The sidelaps are attached with either a button punch or a top seam weld. It is manufactured by Verco Decking Inc. and is the most common metal roof decking panel in the Western United States.

B Floor Deck
B Floor Deck is a composite metal floor deck panel. Composite Floor Decks are meant to have concrete poured over it. This panel has the FormLok embossment pattern on the vertical ribs of the panels which helps create an effective composite slab for greater strength due to the composite design.

What Gauges Are Available For B Decking?
16 Gauge (weighs 3.5 pounds per square foot)
18 Gauge (weighs 2.9 pounds per square foot)
20 Gauge (weighs 2.3 pounds per square foot)
22 Gauge (weighs 1.9 pounds per square foot)

What Finishes Are Available For B Decking?
Type B Deck is available in different finishes. It can come with a Galvanized or Prime Painted finish. The standard finish for type B deck is Galvanized G-60.

Galvanized is a zinc coating over cold-rolled steel. Available in the following options.
G-60 - is a Zinc coating with 0.6 or 6/10 of an ounce of Zinc per square foot. This is the total combined weight of Zinc from the top, bottom, and edges.
G-90 - is a Zinc coating with 0.9 or 9/10 of an ounce of Zinc per square foot. This is the total combined weight of Zinc from the top, bottom, and edges.
Prime Painted is an Acrylic Primer which is applied to cold-rolled steel. Available in the following options.
Gray Primer paint on both sides over bare steel
Gray Primer paint on the bottom side over galvanized deck
White Primer paint on the bottom side over galvanized deck

ABOUT WESTERN METAL DECK
Western Metal Deck specializes in metal roof deck, metal floor deck, metal roofing, and metal siding panels. In order to service our customers in the most efficient and timely manner most panels are available in stock with same day pick-up or delivery. We have a very large selection of gauges, finishes, and lengths. Metaldeck.com also has the ability to cut our stock sizes to match your materials list or to custom run jobs to your specific needs. Shop drawings are also available for your steel deck projects.

Western Metal Deck has two material yards located in Phoenix, Arizona and Ontario, California. In addition, Metaldeck.com has route trucks that service the entire country. We can ship you metal decking immediately and inexpensively.
