Step-by-step maintenance e-guide for Schroedahl – TDL pump protection

Описание: If the time for maintenance on your SCHROEDAHL pump protection system is coming up, this video can help you learn everything you need to know about it. Explore, learn, and prepare yourself for this task before dismantling the system.

It is a step-by-step, precise video guide to efficiently and sustainably check your system's operability. You will learn and get answers to,

Which parts define your pump protection system?
How to disassemble the parts?
How to reassemble the parts correctly?
What are some of the potential problems that may arise?
How to solve those problems efficiently?

CIRCOR International is one of the world’s leading providers of mission-critical flow control products and services. From centrifugal pumps to pump protection valves – we offer you the right fluid-handling solution that meets your needs.

00:00 Disclaimer
00:36 Introduction to Schroedahl TV
00:49 Maintenance & operating instructions
01:00 Things to check before removing the valve
01:34 Remove the flange connection to check the bypass
01:51 Extract the bypass insert from the valve
02:22 Remove the lever
02:53 Remove the bypass orifice from the bypass branch
03:18 Things to do after inspection of bypass
03:34 How to get extra bypass insert stock
03:58 Remove the upper body
04:25 Remove the spring from check valve & examine it
5:39 Install the new gasket & check valve with spring
05:58 Insert the bypass
06:18 Connect the flange
06:34 Affix the upper body
06:44 Tighten the bolts

#valves #maintenance #checkvalve #pumpprotectionsystem #disassemble #reassemble #dismantling #gaskets
