How-To Adjust Shift Cable on Polaris Rzr

Описание: How to adjust the shifter, with the shift cable on your RZR 800 MADE EASY. See some tip on adjustment as well as step by step how to adjust the shift cable on your polaris rzr 800.

Symptoms or Signs Your Shift Cable Needs To Be Adjusted:
See Symptoms Listed From Service Manual Below

Tools Required: (**Optional**)
Crescent Wrench
*Parts Cleaner*
*Small Pick*

Time Required:
1 Beer: (15 Minutes)

0:23 Step 1: Locate the Two Adjusting Nuts
0:43 Step 2: Count Threads
1:01 Step 3: Remove Shift Cable From Bracket
1:21 Step 4: Make Actual Adjustment
1:44 Step 5: Re-Install Shift Cable To Bracket
3:04 Bloopers

Link on how-to replace shift cable
   • How-To Replace Shift Cable on Polaris RZR 800

Want to See More How-To Videos For Your Polaris RZR? Check Out This RZR Maintenance Playlist
   • RZR Maintenance and Upgrades

Found this content helpful or informative? Click here to SUBSCRIBE, we are just getting started.
   / @escapepowersports


Here is all of the info on how to adjust the shift cable from the service manual for this 2014 Polaris RZR 800 S.
Disclaimer: This is Polaris's information/copyright/trademark/whatever and I am not trying to misuse it in anyway just share it with RZR owners who want to keep their machine maintained.


SHIFT CABLE INSPECTION/ADJUSTMENTS
"Lower Jam Nut"= Front Nut pictured in video at 1:02
"Upper Jam Nut"= Back Nut pictured in the video at 1:21

Shift cable adjustment may be necessary if symptoms include:
-No AWD or gear position display on instrument cluster
-Ratcheting noise on deceleration
-Inability to engage into a gear
-Excessive gear lash (noise)
-Gear selector moving out of desired range

1. Locate the shift cable in the rear LH wheel well area.
2. Inspect shift cable, clevis pin, pivot bushings, and dust boot. Replace if worn or damaged.
3. If adjustment is required, loosen the lower jam nut and pull the cable out of the mount to move the upper jam nut.
4. Adjust the shift cable so there is the same amount of cable travel when shifting slightly past the detents of HIGH (H) gear and PARK (P).
5. Thread the upper or lower jam nut as required to obtain proper cable adjustment
NOTE: This procedure may require a few attempts to obtain the proper adjustment
6. Once the proper adjustment is obtained, place the shift cable and upper jam nut into the mount. Tighten the lower jam nut against the mount.
7. Start engine and shift through all gears to ensure the shift cable cable is adjusted. If transmission still ratchets after cable adjustment, the transmission will require service.


So I hope this video helps when it comes when it comes time to adjust the shift cable on your RZR. Thanks for watching and reading, and we'll see ya'll on the trails.
