How to set up EtherCAT Communication with AC20 Variable Speed Drive | Parker Hannifin

Описание: This video shows how to set up the EtherCAT communication option card for the AC20 variable speed drive. In addition to the onboard Modbus TCP/IP, ProfiNet
or Ethernet IP port.

The new AC drive series AC20F was specially developed for motor control in hydraulic applications. It is particularly suitable as a drive controller for the enhanced Drive Controlled Pump (DCP), Parker's variable-speed hydraulic drive solution. The range of functions can be expanded by numerous optional modules. In addition, the AC20F can be equipped with communication cards for fieldbus communication with open standards such as CANopen, PROFIBUS, PROFINET, EtherCAT and Ethernet IP.
This concept makes the new AC20F suitable for OEM machine builders who need a compact, cost-effective and user-friendly drive for their hydraulic applications, but do not want to compromise on performance.

More about AC20F Drive Controller: https://prker.co/3YWkWex

▬ Chapters ▬▬▬▬▬▬▬▬▬▬▬
00:00 Intro
00:17 Connection Architecture
00:23 AC20 Option Card Configuration via DSELite
01:44 Download ESI file from Parker Website
02:09 Installation ESI file into Codesys
02:36 Add AC20 EtherCAT device into Codesys
05:14 Motor Control with AC20 drive
