Singer zigzag sewing machine - How to replace the | gear wheel | Bevel wheel | Bevel gear

Описание: Express Your Love for My YouTube Channel Through Buy Me a Coffee, https://buymeacoffee.com/lakmalkandev...

0:00:00
Remove the face plate and top cover
0:00:02
Remove the stop motion wheel and hand wheel
0:00:30
Loosen the feed regulator lever screw
0:00:32
Remove the handwheel bush and toplon washer
0:00:56
Unscrew and remove the dish track (dish holder).
0:01:37
Unscrew and remove the feed regulator
0:02:37
Unscrew and remove the gear wheel
0:02:39
Loosen the Ascentic pedaling wheel screws
0:02:59
Loosen the main shaft wheel screw
0:03:11
Unscrew and remove the vibrating ascentic shaft and vibrating bracket
0:03:32
It will be convenient for you to remember the location of the two cut marks on the upper end of the vibrating bracket ascentic shaft.
0:03:38
Unscrew and remove the vibrating bracket and the Asentic shaft
0:04:28
Unscrew and remove the needle bar
0:04:33
Unscrew and remove the threadtakeup lever
0:05:25
Loosen the bevel gear screws and the eccentric bearing screws
0:05:30
Pull out the main shaft and remove the broken bevel gear.
0:05:53
Insert the new main shaft wheel into the machine.
0:05:55
Reinstall all previously removed parts as they were before.
0:07:57
Reinstall all previously removed parts as they were before.
0:08:18
Rotate the main shaft so that the threaded take-up lever mounting screws are facing up.
0:08:28
Tighten the bevel gear pin into the cut mark parallel to the threaded take-up lever mounting screw.
0:08:38
Install the eccentric bearing screw on the cut mark opposite the cut mark where the bevel gear screw is installed.
0:08:48
If the two screws on the bevel gear and the eccentric bearing are installed incorrectly, the fabric will be pushed backwards instead of forwards.
0:08:58
Install DishTack now.
0:09:00
Now install the feed regulator.
0:09:30
If you have any further questions, please watch the videos uploaded regarding this repair and this sewing machine.
0:09:40
Install the thread take-up lever and needle bar and vibrating bucket.
0:09:45
Watch the uploaded videos on needle bar timing and needle bar position adjustment.
0:11:45
Thank you for watching the video, please subscribe to the channel.
