Structured Meshing Strategies for Circular Geometry
Автор: Cadence CFD
Загружено: 2019-04-30
Просмотров: 9284
Описание:
In this video we demonstrate three multi-block structured meshing strategies for circular geometry. The first is a traditional H-grid resulting in high included angles in the four corners of the topology. The second approach utilizes a pole, or singularity, to create a high quality structured domain consisting of quadrilateral elements at the core of the topology with collapsed edges. The third, and preferred, approach is known as an O-H-grid consisting of five domains resulting in a high quality structured mesh once elliptic smoothing has been applied.
If you liked this video, then be sure to let us know and subscribe for more videos like this. If you have any comments or questions, then drop us line below or connect with us on Twitter.
