Structured Meshing Strategies for Wing Tips
Автор: Cadence CFD
Загружено: 2019-05-14
Просмотров: 5732
Описание:
In this video we compare two different structured meshing strategies for wing tip geometries. One of the strategies presented results in high included angles near the leading edge of the geometry that can approach 180 degrees as the mesh is refined. The preferred approach is an O-H topology that improves the overall grid quality, particularly near the leading edge of the wing tip.
If you liked this video, then be sure to let us know and subscribe for more videos like this. If you have any comments or questions, then drop us line below or connect with us on Twitter.
Twitter: / pointwise
