Patch of The Week: 'Melodic Doom' - How to use the Entropic Doom noise oscillator melodically

Описание: An improvisation using the Entropic Doom noise oscillator as a melodic instrument, controlled by a step sequencer. It's pretty much a voice in it's own right - a noise source, resonant 4, 3, or 2-pole voltage controlled filter, which will self-oscillate and track a 1V/Oct signal, along with a separate XOR based Ring Modulator and a Cmos gate based VCA. In this video I also use the Sync and audio input functions with a VCO. Additionally, I show the Dual RVG module serving as a master clock to the sequencer, and producing random timing for the sequencer steps, as well as additional random voltages for the Entropic Doom's frequency.
Downloadable Patch Sheet: https://kvisit.com/8AE/-vwG
Patch Notes repeated further down this description.

Check out the AJH Synth playlists for module 'User Guides', and 'Patch of The Week' videos, which will be either performances or 'how to' guides, detailing functions/methods, and a range of sounds, some familiar, some less so, containing a patch sheet at the end to show you how to construct it for yourself.

Video by    / dreamsofwires

More Videos:
Entropic Doom for percussion sounds:    • Patch of The Week: Entropic Doom for Percu...
Ring Mod Comparison - Entropic Doom vs Ring SM:    • Ring Modulator Comparison - The RING SM & ...
Dual RVG Random Event Generator:    • NEW! DUAL RVG Random Voltage Event Generat...

PATCH NOTES:
------------------------
Green dots show approximate pot and switch positions, and where there are 2 dots on the same pot, this indicates the range I adjust them during the video. Pots and switches that do not have green dots are not used in this patch, and should be left at their zero or off positions.
PRECISION VOLTAGES: Used to shift pitch intervals on the Entropic Doom from the incoming sequencer pitch CV. During the video I add 7 semitones and 1 octave at different points using the A switches.
DUAL RVG: This is being used for 2 purposes - To generate random frequency modulation of the Entropic Doom at the start, in addition to the frequency changes generated by the sequencer, which means a wider and more varied range of frequencies can be achieved than just using the pre-chosen frequencies set by the sequencer. It's just to add more randomness and chaos to the initial apocalyptic noises. It is also used to create random sequencer step timing, via it's Time Vary function. It sends gate signals to the sequencer and serves as it's master clock. As I unveil the melody I reduce this time variation until the sequencer timing becomes regular, or normal. The sequencer will need to have some form of Clock Input (perhaps Sync or Gate In), marked here by the green cable.
VCO: This is also connected to the sequencer CV out, either by buffered multiple, or by using CV bus via the Glide + Noise as in the video, then the Glide's CV OUT should go to the Precision Voltages IN A. A triangle wave was used as the Sync source (purple cable), and square was used as the audio source. Tuning here is arbitrary, and dependent on your sequencer.
ENTROPIC DOOM: The base pitch of the module will be set by using the Frequency pots (FREQ-C & FREQ-F) to tune it, once the resonance level is high enough, more clearly so in 4-pole mode. FCV-IN here is only used for the random voltages coming from the Dual RVG, which I gradually remove as I unveil the melody from the sequencer.


Index
00:00 Intro
00:26 'Melodic Doom'
06:30 Patch sheet
