Hydraulic weighing system TC2000-S

Описание: For storage technology vehicles - accuracy ± 0.2% of the load capacity of the vehicle

This stable and high-quality weighing system is specially developed for warehouse trucks. The weighing principle is based on DMD (Dynamic Mass Determination Software) in combination with the TC indicator to guarantee the best weighing result. This system has no effect on the load capacity of the vehicle and can also be used in combination with attachments.

The measuring block is very compact and is installed in the main line to the mast, without return line to the tank. Suitable for
vehicles up to 2.5t.

Features:
· Compact measuring block without return to the tank

· High and stable system accuracy (±0.2%-0.5% of the load capacity depending on the type of industrial truck)
· Components vibration and shock resistant
· Simple mounting and calibration
· No sensors directly on the mast
· Lowering can always be interrupted
· No interference with lift height preselection on reach truck
· Supply voltage 12-80 volts
· Protected against overvoltage
· Optional indicator with stainless steel housing
· Optional Atex version

Weighing procedure:
On the display unit, the weighing process is activated by pressing a key and the load is lowered via the control lever of the lifting function (speed is controlled via the sensor block) until the weight is displayed within approx. 3 seconds.
