How to wire MIDI with Disting EX and Intellijel case
Автор: Johno Wells
Загружено: 2021-08-24
Просмотров: 6528
Описание:
The eurorack synthesizer module: Disting EX, from Expert Sleepers and the Intellijel Performance case can be a powerful combo if wired correctly. In this video, I show how to figure out the different pin-outs on these two devices and make them talk together nicely.
I wanted to figure this out so I could use my Arturia Keystep with the Disting EX without having to use a MIDI breakout module.
Enjoy!
0:00 - Intro to the project
1:20 - Pin-out of the Disting EX
1:40 - Pin-out of the Intellijel 7U case
2:10 - Turn your case around-work from behind
2:26 - Orientation of the Intellijel schematic (my "a-ha" moment)
2:44 - Jumper-wires used (also linked below)
3:01 - PAUSE ON THESE SCREENS
3:24 - Finished!
These are the jumper-wires I mention in the video:
GenBasic 40 Piece Female to Female Jumper Wires (8 Inch) $5
https://www.amazon.com/gp/product/B07...
If you'd still like to use a midi breakout module--Expert Sleepers now has a 2HP option!
https://www.expert-sleepers.co.uk/tin...
