Finish Strong Friday: Solving for Unknowns with Subassembly Composer

Автор: Alan Gilbert

Загружено: 2017-06-25

Просмотров: 6723

Описание: In this short video, I show a technique for creating a subassembly in the Subassembly Composer application that will solve for an unknown parameter within a side slope design. This will be accomplished by changing the order of the geometry and employing Auxiliary Points to "back in" our solution.

If you'd like help getting started with Subassembly Composer before jumping into this example, please refer to Jeff Bartels' "Quick Start" playlist that can be found here: • Subassembly Composer Pt. 1 - Exploring the...

Learn more tips and tricks at http://civilimmersion.typepad.com
