CLASSIC BROADHEAD TEST: MUZZY 3 BLADE

Описание: This is a test of the 100 gr Muzzy 3 blade broadhead.

Here is summary of my 2023 Testing Procedure & Scoring w/the scores of this head posted in parenthesis as well.

Muzzy 3 Blade Total Score: 81.91 = 8 Golden Arrows

1. Flight Forgiveness (20%, 15 pts)
This is not just a test of how heads fly out of my bow, as it was in the past. With a well tuned bow, properly built arrows & good form, almost every head flies well. That's why in the past most heads got a flight score of 9 or 10. But that doesn't help those who may not have perfectly tuned bows/arrows/good form. So now I am gauging Flight Forgiveness. This is based on how the head flies for me, how well it spins, how "sensitive" the flight is to imperfections, & the exposed surface area of the blades. The max score of a Mech is 20 & the max score of a Fixed is 16.

2. Cut Size (20%, 13.52 pts)
The more tissue being cut, the more lethal the head, all else equal. The entrance cut, total cut, & width of the cut (a crucial variable for bloodletting) are all scored:
The entrance cut size is compared to a standard of 2.5" then that fraction is weighted to 7% of the score. (1.78" = 4.98 pts)
The max cut size is compared to a standard of 2.5" as well, then that fraction is is weighted to 7% of the score. (1.78" = 4.98 pts)
The max cutting diameter is compared to a standard of 2.0", then that fraction is weighted to 6% of the score. (1.19" = 3.56 pts)

3. Blades (20%, 16.55 pts)
Initial sharpness (9%, 175 grams = 10/10 = 9 pts) & Edge Retention (9%, +125 gram = 7.5/10 = 6.65 pts) are measured using the Edge On Up Sharpness Tester. The pressure needed for a blade to cut thru a copolymer wire is measured in grams.
Edge Retention is the loss of sharpness after the head is shot in Penetration Test 1, thru 1/2" MDF and 2/3" rubber foam mat & Clear Ballistics FBI gel. For every 50 "grams" of sharpness lost, 1 point is deducted from 10.

What are some sharpness scores for common edges?
A butter knife takes 2000 grams of pressure to break the co polymer wire.
A new high end cutlery edge: ~ 375 grams of pressure.
A utility razor blade: 200 grams.
Based on the many broadheads I have tested, here is my scoring scale:
Out of the Box Sharpness:
0-200 gr: 10
201-300 gr 9
301-400 gr: 8
401-500 gr: 7
501-600 gr: 6
601-700 gr: 5
Ease to resharpen or replace blades is judged & given 2% of the score. (4/10=.8 pts)

4. Penetration (20%, 17.34 pts)
There are 3 penetration tests:
Pen Test 1: 1/2" MDF, 2/3" rubber foam mat, Clear Ballistics FBI gel. Depth of penetration is compared to a standard of 9" & weighted to 9% of the score. (7.75" = 7.75 pts)
Pen Test 2: Layered cardboard. # of layers penetrated is compared to a standard of 70 layers & weighted to 9% of the score.
(59 layers=7.59 pts)
Angled Penetration Test: How effectively does the head penetrate 1/4" MDF covered by carpet at a 45 degree angle. This accounts for 2% of the score. (10/10 = 2 pts)

5. Durability (20%, 17.5 pts)
Each head is shot thru 1/2" MDF 3 times. Its condition is judged 1-10 & weighted to 12% of the score. (10/10 = 12 pts)
If a head survives that, it is then shot thru 22 ga steel plate twice. Its condition is judged 1-10 & weighted to 5% of the score. (5/10 = 2.5 pts)
If a head survives that, it is then shot into concrete once. Its condition is judged 1-10 & weighted to 3% of the score. (10/10 = 3 pts)
Steel plate & concrete are certainly not "realistic" mediums, but they do reveal the outer limits of a head's durability.

BONUS: 0

Total Muzzy 3 BladeSCORE: 79.91 pts = 8 Golden Arrows

Price: $7.50/head (6 pack)

Special Notes:
