MUZZY TROCAR HB TI 100 gr: BROADHEAD TEST

Описание: This is a test of the 100 gr Trocar HB TI Broadhead by Muzzy.
Here is summary of my 2024 Testing Procedure & Scoring w/the scores of this head posted in parenthesis as well.

1. Flight Forgiveness (20%, 18 pts)
I'm using a Killer Instinct SWAT X1 crossbow, mounted to a BOG tripod, shooting a 670 gr Bishop Archery GOAT bolt (300 fps) at 30 yds. Field points consistently hit in the 10 ring & bullseye. I use the exact same bolt to shoot the broadhead. The only difference in the two shots is the broadhead's flight forgiveness vs that of the field point. A bullseye gets a score of 11/10, or a perfect score of 20 + 1 Bonus Point. The 10 ring gets a 10/10, or 20 points; a 9 ring gets a 9/10 or 18 points...& so forth, with each wider ring being 1/2" farther from the bullseye. Mechs are also given 1 Bonus Point for extra forgiveness.

2. Cut Size (20%, 17.06 pts)
The more tissue being cut, the more lethal the head, all else equal. The entrance cut, total cut, & width of the cut (a crucial variable for bloodletting) are all scored:
The entrance cut size is compared to a standard of 2.5" then that fraction is weighted to 7% of the score. (1"+.7" = 1.7" = 4.76 pts)
The max cut size is compared to a standard of 2.5" as well, then that fraction is is weighted to 7% of the score. 2.625”=7pts+.35 bonus=7.35pts
The max cutting diameter is compared to a standard of 2.0", then that fraction is weighted to 6% of the score. (1.625" = 4.95 pts)

3. Blades (20%, 18.37 pts)
Initial sharpness 9%, 168 grams = 10/10 = 9 pts +.32 bonus = 9.32 pts & Edge Retention (9%, +30.5 grams = 9.39/10 = 8.45 pts) are measured using the Edge On Up Sharpness Tester. The pressure needed for a blade to cut thru a copolymer wire is measured in grams.
Edge Retention is the loss of sharpness after the head is shot in Penetration Test 1, thru 1/2" MDF & 2/3" rubber foam mat & Clear Ballistics FBI gel. For every 50 "grams" of sharpness lost, 1 point is deducted from 10.

What are some sharpness scores for common edges?
A butter knife takes 2000 grams of pressure to break the co polymer wire.
A new high end cutlery edge: ~ 375 grams of pressure.
A utility razor blade: 200 grams.
Based on the many broadheads I have tested, here is my scoring scale:
Out of the Box Sharpness:
0-200 gr: 10
201-300 gr 9
301-400 gr: 8
401-500 gr: 7
501-600 gr: 6
601-700 gr: 5

Ease to resharpen or replace blades is judged & given 2% of the score. (3/10= .6 pts)

4. Penetration (20%, 13.01 pts)
There are 2 penetration tests:
Pen Test 1: 1/2" MDF, 2/3" rubber foam mat, Clear Ballistics FBI gel. Depth of penetration is compared to a standard of 9" & weighted to 10% of the score. (8.5" = 9.44 pts - 1 pt: blades not deployed = 8.44 pts)
Pen Test 2: Layered cardboard. # of layers penetrated is compared to a standard of 70 layers & weighted to 10% of the score.
( 32 layers= 4.57 pts)

5. Durability (20%, 14.8 pts)
Each head is shot thru 1/2" MDF 3 times. Its condition is judged 1-10 & weighted to 12% of the score. (10/10 = 12 pts)
If a head survives that, it is then shot thru 22 ga steel plate twice. Its condition is judged 1-10 & weighted to 5% of the score. (2/10 = 1 pt)
If a head survives that, it is then shot into concrete once. Its condition is judged 1-10 & weighted to 3% of the score. (6/10 = 1.8 pts).
Steel plate & concrete are certainly not "realistic" mediums, but they do reveal the outer limits of a head's durability.

Additional Bonus: +1 no O rings/clips

TOTAL SCORE: 82.24 pts = 8 Golden Arrows

Price: $18.33/head
